Condition New
Place of Origin Jiangsu, China
Brand Name Quanbang
Model Number YCCC
Structure Tube Heat Exchanger
Liquid Flow Rate customized
Maximum Working Pressure customized
Weight customized
Dimension(L*W*H) customized
Certification Other, TUV
Warranty 1 year
After-sales Service Provided No overseas service provided
Domestic waste heat exchanger for waste gas and water
This kind of heat exchangers are to reuse waste gas, waste water etc.  for energy saving . Mainly applied in Chemical Industry, Cereals and Oil Industry, Feed Processing Industry and so on.
Product Description

Type: Compact Heat Exchanger

Heat transfer source: waste gas, waste water

Pressure-bearing: High

Heat transfer Function: medium level

Material feature: carbon steel tube with high frequency welding carbon steel fin, outer frame spray painted.

Array: staggered arrangement

Fin Shape:

Domestic waste heat exchanger for waste gas and water





Performance Parameter



Model

Air Flow(m3/h)

Windward

Tubes

Effective

Height
(mm)

Heat Exchange

Area
(m2)

Header Tube

Diameter
(mm)

Heat Load(kw)

L×W×H
(mm)




YCCC-14×6×0.5

5000

14

575

47

φ57×3.5

69

900×600×679



YCCC-15×6×0.8

8000

15

823

72

φ76×4

111

1000×600×923



YCCC-17×6×0.9

10000

17

926

92

φ76×4

138

1100×600×1026



YCCC-20×6×1.1

15000

20

1157

135

φ89×4.5

208

1300×600×1257



YCCC-22×6×1.2

18000

22

1282

164

φ89×4.5

249

1400×600×1382



YCCC-24×6×1.3

20000

24

1323

185

φ89×4.5

277

1500×600×1423



YCCC-27×6×1.4

25000

27

1447

227

φ114×6

346

1700×600×1547



YCCC-29×6×1.5

28000

29

1525

257

φ114×6

388

1800×600×1625



YCCC-29×6×1.6

30000

29

1634

276

φ114×6

415

1800×600×1734





Packaging & Shipping

Packaging according to custmer's requirement



Shipping Port: Shanghai



Domestic waste heat exchanger for waste gas and water

Application Field

 Applied in Drying Installations, Food Processing and Chemical Industry etc.



Domestic waste heat exchanger for waste gas and water





ISO Certificate

 Domestic waste heat exchanger for waste gas and water
