Help CenterIGBT INVERTER SUBMERGED-ARC WELDER
Related Products
Specifications
three adjustable knobstwo metal switches
two digital displays
designed with advanced dual-track tubular framework
For control panel of MZ-1000 IGBT inverter submerged arc welder, there are three adjustable knobs for regulation of current, arc and arc characteristic.
As well as that, there are two metal switches for thin/thick wire and submerged arc welding, manual welding and carbon arc gouging. Besides that, two digital displays can be seen from the panel, standing for current and voltage respectively.
A tractor weighted 45 kg are equipped with the product and it is designed with advanced dual-track tubular framework, which ensures stable welding operation and single and twin-wire submerged arc welding. Both welding speed and wire feeding speed of MZ-1000 IGBT inverter submerged arc welder can be steplessly adjusted, 20-150 cm/min for welding speed and 30-360 cm/min for wire feeding speed.
| Input power | 3×380V 50/60HZ |
| Rated Input Power | 58KVA |
| Rated Input Current | 80A |
| Duty Cycle | 100% |
| No-load voltage | 70-90V |
| Adjustment range of current(MMA) | 50-1000A |
| Adjustment range of current(SAW&CC) | 100-1000A |
| Adjustment range of current(SAW&CV) | 17V-50V |
| Diameter of wire | 2.5-5mm |
| Weight of welder | 105KG |
| Dimension(L×W×H) | 720×420×1000mm |
| Wire feeding speed | 30-360cm/min |
| Welding speed | 20-150cm/min |
| Capacity of flux container | 10L |
| Capacity of wire container | 20KG |
| Weight of tractor | 45KG |
| Air Switch | 100A |
| Insulation class | F |
| Raising means | LIFT |
| Protection grade | IP21S |
