IGBT INVERTER SUBMERGED-ARC WELDER
Negotiable
MOQ: 5 Cartons (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Jiangsu, China
Brand Name:
hongri
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Condition
New
Place of Origin
Jiangsu, China
Brand Name
hongri
Model Number
MZ-1250
Motor Type
AC Motor
Dimensions
720*420*1000mm
Voltage
3*380V
Power(W)
73KVA
Warranty
one year
After-sales Service Provided
Engineers available to service machinery overseas
Specifications
greatest weightbiggest dimension, power and output current
mainly applied for gouging and eliminating weld defects
|
MZ-1250 IGBT inverter submerged arc welder has the greatest weight, biggest dimension, power and output current in this series.
The dimension, net weight and output current are 3.1 times, 1.9 times and 1.98 times of model MZ-630 and lifting equipment or casters on the bottom should be used to move this giant machine.
Apart from this feature, MZ-1250 IGBT inverter submerged arc welder can be used as carbon arc gouging machine by simple adjustment. In real practice, carbon arc gouging is mainly applied for gouging and eliminating weld defects.
However, a word of warning, please take care because carbon arc operation can cause smoke, dust pollution and arc radiation.
|
| Input power | 3×380V 50/60HZ |
| Rated Input Power | 73KVA |
| Rated Input Current | 101A |
| Duty Cycle | 100% |
| No-load voltage | 70-90V |
| Adjustment range of current(MMA) | 60-1250A |
| Adjustment range of current(SAW&CC) | 120-1250A |
| Adjustment range of current(SAW&CV) | 17V-50V |
| Diameter of wire | 2.5-6mm |
| Weight of welder | 110KG |
| Dimension(L×W×H) | 720×420×1000mm |
| Wire feeding speed | 30-360cm/min |
| Welding speed | 20-150cm/min |
| Capacity of flux container | 10L |
| Capacity of wire container | 20KG |
| Weight of tractor | 45KG |
| Air Switch | 100A |
| Insulation class | F |
| Raising means | LIFT |
| Protection grade | IP21S |
