Specifications
1.Decreasing the maintenance cost of equipments2.Reduce the energy consumption of equipment
3.Improve the operation rate
Product Function
High wear resistance
(1)20- 25 times harder than low carbon steel
(2) 5-20 times harder than high manganese steel
(3) 5-10 times harder than tool steel
(4) 1.5-2.5 times harder than high-chromium steel
Virtual Show
Premium Grades Wear Resistant Steel Pipe
PRODUCED RK-200 Wear Resistant Pipe(HRC 55-58)
PRODUCED RK-400 Wear Resistant Pipe (HRC 58-62)
PRODUCED RK-200 Wear Resistant Pipe(HRC 62-67)
Chemical Composition(WT%)
| C | 5.0 |
| Si | 1.0-1.5 |
| Mn | 0.8-1.2 |
| Cr | 27.0 |
| B | + |
| Re | + |
| Other | ≤2.0 |
Instructions
Wear resistant pipeline is the newest high level wear resistant pipe in the world and it is developed by Zhangjiagang Runkun Wear Resistant Material Co., Limited. The base layer is Q235 metal and it is lined with wear resistant alloy materials. One method of producing the pipes is by inner wall welding machine; the machine can also apply to produce wear resistant pipes with small diameter. The other method of producing the pipe is by curling the wear resistant plate. Our factory can produce any pipe with diameter greater than 80mm.
Brand Introduction
| Base metal | structure steel,alloy steel |
| Brand | RK |
| Color | brown |
| Diameter | ≥80mm(can be customized) |
| Thickness of wear resistant layer | as customer's requirement |
| Thickness of pipe wall | 5-30mm |
| Length | can be customized |
| Hardness | HRC57-62 |
| Standard | DIN,GB |
| Certificates | ISO9001:2000 |
| Specifications (base layer+wear resistant layer) |
5+3,6+3,8+3,5+4,6+4,8+4,10+4,6+5,8+5,10+5, 15+5,20+5,6+6,8+6,10+6,20+6,8+8,10+8,10+10, 15+10,20+10 |
| Model number | steel plate Q235 |
| Grade | first class |
| Applications | concrete industry,metallurgy,fan industry,coal industry,mining machinery,construction machinery,etc. |
| Payment terms | L/C,TT,D/P,Western union |
| Delivery time | 15 days after receipt of L/C or advanced payment |
| Trade terms | FOB,CIF,EXW,etc |
| Port | shanghai |
Factory and workshop
Certificates show
