Specifications
1. Decreasing maintenance cost of equipments2. Reducing energy consumption of mill equipment
3. Improving operation rate
Products
Abrasion resistant steel piping is the newest high level wear resistant pipe in the world and it is developed by abrasion resistance pipe manufacturers --Zhangjiagang Runkun Wear Resistant Material Co., Limited. The base layer is Q235 metal and it is lined with wear resistant alloy materials. One method of producing the pipes is by inner wall welding machine; the machine can also apply to produce wear resistant pipes with small diameter. The other method of producing the pipe is by curling the wear resistant plate. Our factory can produce any pipe with diameter greater than 80mm.
Chemical composition,mechanical properties and metallographic examination
C |
Si |
Mn |
Cr |
other |
4.0~5.5 |
0.5~1.5 |
0.5~2.5 |
24.0~30.0 |
less than 2.0 |
HRC 55-60
HRC 61-65
Specifications
| Name | Abrasion resistant steel piping |
| Brand | RK |
| Color | brown |
| Diameter | as customer's require |
| Thickness of wear resistant layer | as customer's require |
| Thickness of pipe wall | 5-30mm |
| Length | can be customized |
| Hardness | HRC57-62 |
| Standard | DIN,GB |
| Certificates | ISO9001:2000 |
| Specifications (base layer+wear resistant layer) |
5+3,6+3,8+3,5+4,6+4,8+4,10+4,6+5,8+5,10+5, 15+5,20+5,6+6,8+6,10+6,20+6,8+8,10+8,10+10, 15+10,20+10 |
| Model number | steel plate Q235 |
| Grade | first class |
| Applications | concrete industry,metallurgy,fan industry,coal industry,mining machinery,construction machinery,etc. |
| Payment terms | L/C,TT,D/P,Western union |
| Delivery time | 15 days after receipt of L/C or advanced payment |
| Trade terms | FOB,CIF,EXW,etc |
| Port | shanghai |
