light weight full color smd3528 p5 indoor led sign

FOB Price

US$ 1,000 - 3,000 / Square Meter

1 Square Meter(Min. Order)

Port Shenzhen
Payment TermsCredit Card PayPal

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	China	Brand Name	Proge p5 indoor led sign
Model Number	PG-IFC-P5	Usage	Indoor
Tube Chip Color	Full Color	Display Function	Video
Pixels	Other, 5mm	Screen Dimension	p5 indoor led sign

Product Description

light weight full color smd3528 p5 indoor led sign

Features:

1) Price Advantage: We have the best competitive price at the market, also have the same even better quality.
2) Performance Advantage: Best Equality, high consistency, Big viewing angle, can repair each LED lamps
3) Quality advantage: From material to finished product, from design to produce, we control all steps, that's the guarantee of the quality and reliability.
4) Service advantage: Better service at same situation, better cooperation at same service!

Specification:

Indoor full color led display screen technical parameter
Items	P5 full color indoor led display
Pitch size	5mm
Module size	320mm*160mm
Module pixel(dots)	64dots*32dots
Pixel configuration	1Red, 1Green, 1Blue
LED chip	Silan
Color scale	65536degree/16777216colors
Pixel density	40000pixels/square meter
View angle(H/V)	≥ 120/120degree
Brightness	≥ 800cd/square meter
Brightness adjustment	64 level automatic or manual
View distance	3--100m
Power consumption	100-1600W/square meter
Net weight	less than 45kg/square meter
Operating temperature	_ 25° C~+60° C
Operating humidity	10%_ 95%RH
Life time	≥ 100, 000hours
Out of control dot	≤ 1/10, 000
Whole Display Flatness	≤ 1mm Juncture
Exchange frame speed	> 150frames per second
Refresh frame frequency	600Hz
Control distance	120m (without repeater), single mode fiber: 20km, multi mode fiber: 500m
Power	110V/220V± 15% 50Hz
Operating system	Windows98/Me/2000/Xp
Drive mode	constant current driving, 1/8 scan
Display mode	VGA640X480_ VGA1600X1024
Protections for outdoor display	IP31
Maintenance way	Rear access
Accepting signal	PAL/NTSC/SECAM, S-Video; VGA; RGB; Composite Video; SDI

light weight full color smd3528 p5 indoor led sign
