Light Weight Indoor Full Color p5 Smd3528 Led Display

Light Weight Indoor Full Color p5 Smd3528 Led Display thumbnail-1
Light Weight Indoor Full Color p5 Smd3528 Led Display photo-1
US$ 1,000 - 3,000 MOQ: 1 Square Meter
Key Specifications
Get Latest Price
Place of Origin:
China
Brand Name:
Proge smd3528 led display
Model Number:
PG-IFC-P5
Contact Supplier Request Quote Chat Now
Shenzhen Proge Electronics Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin China
Brand Name Proge smd3528 led display
Model Number PG-IFC-P5
Usage Indoor
Tube Chip Color Full Color
Display Function Video
Pixels Other, 5mm
Screen Dimension smd3528 led display

full color smd 3528 indoor p5mm xxx small led display

Features:

1) Price Advantage: We have the best competitive price at the market, also have the same even better quality.
2) Performance Advantage: Best Equality, high consistency, Big viewing angle, can repair each LED lamps
3) Quality advantage: From material to finished product, from design to produce, we control all steps, that's the guarantee of the quality and reliability.
4) Service advantage: Better service at same situation, better cooperation at same service!



Specification:



Indoor full color led  display screen technical  parameter
Items  P5 full color indoor  led  display
Pitch  size 5mm
Module  size 320mm*160mm
Module  pixel(dots) 64dots*32dots
Pixel  configuration 1Red, 1Green, 1Blue
LED  chip Silan
Color  scale 65536degree/16777216colors
Pixel  density 40000pixels/square  meter
View  angle(H/V) ≥ 120/120degree
Brightness ≥ 800cd/square meter
Brightness  adjustment 64  level  automatic  or  manual
View  distance 3--100m
Power  consumption 100-1600W/square meter
Net  weight less than 45kg/square  meter
Operating  temperature _ 25° C~+60° C
Operating  humidity 10%_ 95%RH
Life  time ≥ 100, 000hours
Out  of  control  dot ≤ 1/10, 000
Whole  Display  Flatness ≤ 1mm  Juncture
Exchange  frame  speed > 150frames  per  second
Refresh  frame  frequency 600Hz
Control  distance 120m  (without  repeater),   single  mode  fiber: 20km,                                                           multi  mode  fiber:   500m
Power  110V/220V± 15%  50Hz
Operating  system Windows98/Me/2000/Xp
Drive  mode constant  current  driving,   1/8  scan
Display  mode VGA640X480_ VGA1600X1024
Protections  for  outdoor  display    IP54
Maintenance  way Rear  access
Accepting  signal PAL/NTSC/SECAM, S-Video; VGA; RGB; Composite  Video; SDI



light weight indoor full color p5 smd3528 led display



light weight indoor full color p5 smd3528 led displaylight weight indoor full color p5 smd3528 led display



 light weight indoor full color p5 smd3528 led displaylight weight indoor full color p5 smd3528 led display
