Home > Consumer Electronics > LED Display > Indoor LED Display > Good Quality Smd1010 Full Color hd Indoor P1.92 Led Wall
Good Quality Smd1010 Full Color hd Indoor P1.92 Led Wall
US$ 8,000 - 9,000
MOQ: 1 Square Meter
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
Proge p1.92 led wall
Model Number:
PG-IFC-P1.92
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
China High Quality Smd1010 Full Color Indoor P1.66 hd Led Video WallUS$ 9,500 - 10,500MOQ: 1 Square Meter -
Smd1010 Full Color hd Indoor P1.56 Led Video WallUS$ 11,000 - 12,000MOQ: 1 Square Meter
-
High Definition Indoor Smd1010 Full Color P1.56 Led DisplayUS$ 11,000 - 12,000MOQ: 1 Square Meter
-
High Definition Indoor Smd1010 Full Color P1.56 Led ScreenUS$ 11,000 - 12,000MOQ: 1 Square Meter
-
High Definition Indoor Smd1010 Full Color p2 Led Video WallUS$ 6,500 - 7,500MOQ: 1 Square Meter
Place of Origin
Guangdong, China
Brand Name
Proge p1.92 led wall
Model Number
PG-IFC-P1.92
Usage
Indoor
Tube Chip Color
Full Color
Display Function
Video
Pixels
Other, 1.92
Screen Dimension
p1.92 led wall
good quality smd1010 full color hd indoor p1.92 led wall
Technical Parameters:
| P1.92 Indoor High Definition LED video wall | ||||||||
| S/N | Item | Technical Parameters | ||||||
| LED Parameters | ||||||||
| 1 | Item Name | LED Type | Brightness | Wave Length | H/V Visual Angle | |||
| 2 | Red LED | SMD1010 | 100-120mcd | 620-625nm | 140º/60º | |||
| 3 | Green LED | SMD1010 | 320-400mcd | 520-525nm | 140º/60º | |||
| 4 | Blue LED | SMD1010 | 70-90mcd | 470-475nm | 140º/60º | |||
| Module Specifications | ||||||||
| 1 | Pixel Pitch | 1.92mm | ||||||
| 2 | Pixel Configuration | SMD3in1 | ||||||
| 3 | Module Resolution | 104x156 pixels | ||||||
| 4 | Module Pixles | 16.224pixels | ||||||
| 5 | Module Size | 200x300mm | ||||||
| Cabinet Specifications | ||||||||
| 1 | Cabinet Size(W X H X D) | 400x300mm | ||||||
| 2 | Cabinet Resolution(dot) | 208 x 156 pixels | ||||||
| 3 | Module Quanity (pcs) | 2pcs | ||||||
| 4 | Cabinet Pixels | 32,448 pixels | ||||||
| 5 | Pixel Density | 270400 pixels/m2 | ||||||
| 6 | Cabinet Materials | Die Casting Aluminum | ||||||
| Whole Screen Specifications | ||||||||
| 1 | Screen Brightness | ≥800cd/m2 | ||||||
| 2 | Driving Method | 1/26 scan | ||||||
| 3 | Mini Viewing Distance | 2m | ||||||
| 4 | Max. Power Consumption | 800W/m2 | ||||||
| 5 | Average Power Consumption | 400W/m2 | ||||||
| 6 | Gray Level | 8bits input, 4096 levels(212) | ||||||
| 7 | Display Color | 16M | ||||||
| 8 | Frame Frequency | ≥60Hz | ||||||
| 9 | Refresh Frequency | ≥2000Hz | ||||||
| 10 | Uninterrupted Working Hours | ≥72 hours | ||||||
| 11 | Screen Life-span | ≥100,000 hours | ||||||
| 12 | MTBF | ≥5,000 hours | ||||||
| 13 | Discrete Blind Spot Rate | <1/10000 | ||||||
| 14 | Continuous Blind Spot Rate | None | ||||||
| 15 | Blind Spot Rate | <1/10000 | ||||||
| 16 | Screen Plainness | <±1mm | ||||||
| 17 | Power Supply Mode | AC220±10% 50Hz/AC110±10% 60Hz | ||||||
| 18 | Environment Temperature & Humidity | Temperature:-20 Celsius~+60 Celsius Humidity:10%~90% RH |
||||||
| 19 | Control Mode | Synchronous display with control PC by DVI | ||||||
| 20 | Control System | DVI video card + full color control card + fiber system( optional) | ||||||
| 21 | Display Content | Video, DVD, VCD, TV, picture, cartoon, graphics, texts.etc. | ||||||
| 22 | Interface | Standard Ethernet | ||||||
| 23 | Transmission Distance | Multi mode fiber <500m, single mode fiber <30km,internet cable <100m | ||||||
