Home > Health & Medicine > Medical Supply > Disposable Medical Supplies > Air Shield 6.867K Temperature Probe/ Sensor for Pediatric Skin, 3m, Din 3pin

Air Shield 6.867K Temperature Probe/ Sensor for Pediatric Skin, 3m, Din 3pin

Air Shield 6.867K Temperature Probe/ Sensor for Pediatric Skin, 3m, Din 3pin photo-1
Air Shield 6.867K Temperature Probe/ Sensor for Pediatric Skin, 3m, Din 3pin photo-2
Air Shield 6.867K Temperature Probe/ Sensor for Pediatric Skin, 3m, Din 3pin photo-3
Air Shield 6.867K Temperature Probe/ Sensor for Pediatric Skin, 3m, Din 3pin photo-4
Air Shield 6.867K Temperature Probe/ Sensor for Pediatric Skin, 3m, Din 3pin photo-5
US$ 10 - 20 MOQ: 1 Piece
Key Specifications
Get Latest Price
Properties:
Other, Medical Materials & Accessories
Type:
Other, Surgical Supplies
Brand Name:
Air shield, Air shield
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen/Hongkong/Guangzhou
Delivery Detail:
Delivery time depends on order quantity.
Properties Other, Medical Materials & Accessories
Type Other, Surgical Supplies
Brand Name Air shield, Air shield
Model Number BTS-04B
Place of Origin Guangdong, China
Product Description
Air shield 6.867K Temperature Probe/ Sensor for Pediatric Skin, 3m, Din 3pin

.
    Product Number
BTS-04B
       Cable
PVC 3M
       Color
Dark Grey
    accuracy
0.5%
     Resistor
6.867K
    Connector
Din 3pin plug>> Diameter 8.0mm disk
   Connector Material
Nylon and Medical PVC with Gold-plated Pins
   Specification
For Adult or Pediatric ; For Skin or Rectal
                                                                  25℃ Resistor Acceptable Accuracy:±0.5%
Temperature
MAX(Ω)
Stardard (Ω)
Min(Ω)
0
7477.62
7352.89
7230.07
1
7102.68
6987.77
6874.54
2
6748.74
6642.91
6538.58
3
6414.51
6317.10
6221.02
4
6098.80
6009.19
5920.74
5
5800.48
5718.09
5636.73
6
5518.37
5442.68
5367.88
7
5251.62
5182.12
5113.42
8
4999.30
4935.55
4872.49
9
4760.56
4702.13
4644.30
10
4534.60
4481.10
4428.12
11
4320.65
4271.72
4223.24
12
4118.03
4073.33
4029.01
13
3926.06
3885.28
3844.83
14
3744.14
3706.99
3670.12
15
3571.68
3537.89
3504.34
16
3408.14
3377.47
3346.99
17
3253.01
3225.22
3197.59
18
3105.82
3080.70
3055.70
19
2966.11
2943.46
2920.91
20
2833.47
2813.11
2792.82
21
2707.48
2689.23
2671.04
22
2587.80
2571.52
2555.27
23
2474.09
2459.62
2445.16
24
2366.02
2353.21
2340.42
25
2263.26
2252.00
2240.74
26
2167.42
2155.70
2143.98
27
2076.17
2064.04
2051.93
28
1989.25
1976.78
1964.33
29
1906.44
1893.67
1880.94
30
1827.52
1814.51
1801.54
31
1752.29
1739.07
1725.91
32
1680.54
1667.16
1653.85
33
1612.11
1598.61
1585.17
34
1546.82
1533.22
1519.70
35
1484.52
1470.85
1457.28
36
1425.19
1411.49
1397.89
37
1368.54
1354.82
1341.22
38
1314.42
1300.72
1287.14
39
1262.73
1249.06
1235.51
Compatible machines
It can be used for monitors with high accuracy and fast data.
Compatible with Air Shield.
Detailed Pictures
Certificates

          ISO 13485 DNV                                                                             CE DNV



           ROHS Certificate                                                                        ROHS Report







         Biocompatiblity Report                                                 Biocompatiblity Report

            Vitro Cytotoxicity Test                                                                  Skin Sensitization Test



         Biocompatiblity Report                                                          Import and Export License

             Skin Irritation Test

   Record of Foreign Trade Operators                             Entry and exit quarantine enterprises

                                                                                                              for the record


Warranty

We guarantee that all our products will work at the best of their ability,free of non-artificial damage within the following warranty period:

Reusable SpO2 Sensor
12 Months
SpO2 Adapter Cable
6 Months
ECG Cable and Leadwires
6 Months
EKG Cable and Leadwires
6 Months
IBP Cable
12 Months
Temperature Probe
6 Months
Reusable NIBP Cuff and Hose Tube
6 Months
Disposable NIBP Cuff and SpO2 Sensor
If no faults are found while using at the first time, there is no warranty.

Problematic Products could be reparied or exchagned when they are returned to Best fatory,provided that failures are found within warranty period.If no faults are found by Best or items are out of warranty,the customers should pay for the shipping cost.
