Negotiable
MOQ: 2 Cartons (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
Spark LED Street Light
Model Number:
SPL-D120
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Spark 40W COB LED Street LightNegotiableMOQ: 2 Pieces -
Spark 180W COB LED Street Light 95lm/wNegotiableMOQ: 2 Pieces
-
Spark High Power COB LED Street Light 160WNegotiableMOQ: 2 Pieces
-
Spark High Lumen Single Lens 150W LED Street Light With CE ROHS PSENegotiableMOQ: 2 Pieces
-
Spark CE RoHS UL Listed Super Bright Walkways LED Street LightNegotiableMOQ: 2 Pieces
Place of Origin
Guangdong, China
Brand Name
Spark LED Street Light
Model Number
SPL-D120
Power Supply
AC
Application
Highway
Lampshade Material
Toughened Glass
Spark 2014 Module LED street lights with UL, PSE, VDE and IP66 IP Rating
- Environmental friendly with no mercury content
- LED as light source offer very long life as compared to conventional source
- Wide operating voltage of 100-277V
- Color rendering index (CRI) >70
- Pre-wired, easy installation
- Warm white, pure white and cool white available
- Compact design, less weight and high cost performance.
A unique, modular design with enhanced optic-lense, makes this IP66-rated area luminaire the most versatile to date, providing exceptional lighting performance and reduced total cost of ownership in variety of applications. The modular design accommodates up LEDs to allow for customization of illumination and economic performance for a wide range of applications. The advanced thermal management system contributes to unparalleled lumen maintenance.
Application:
Highway, Factories, Hospitals, Government, Public Buildings, Community etc.
Main Technology Index:
| Model No. | SPL-D120 |
| Total Power | 120W |
| Luminous Flux | 10200-12000lm |
| Luminous Efficiency | 85-100 lm/W |
| Input Voltage | 100-277VAC |
| Beam Angle | 145° x 75° |
| Power Factor(PF) | 0.95 |
| IP Rating | IP66 |
| Power Efficiency | 90% |
| CCT | Warm White:3000-3500K; Pure White:4000-4500K; Cool White:5000-5700K |
| CRI | Ra>70 |
| Frequency Range | 47-63 Hz |
| Storage Temperature | -40°C--+80°C |
| Working Temperature | -40°C--+50°C ; 10%-90%RH |
| Lamp Body Material | Aluminum Alloy |
| Net Weight | 7.7kg |
| Gross Weight | 9.3kg |
| Product Size | 755x288x147mm |
| Package Size | 877×355×238mm |
| Products must be connected to the earth wire | |
