Home > Lights & Lighting > LED Outdoor Lighting > LED Street Light > Spark 180W COB LED Street Light 95lm/w

Spark 180W COB LED Street Light 95lm/w

Spark 180W COB LED Street Light 95lm/w thumbnail-1
Spark 180W COB LED Street Light 95lm/w photo-1
Negotiable MOQ: 2 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
LED Light Source:
COB LED
Input Voltage(V):
90-305VAC
Lamp Power(W):
180
Contact Supplier Request Quote Chat Now
Shenzhen Spark Optoelectronics S&T Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
LED Light Source COB LED
Input Voltage(V) 90-305VAC
Lamp Power(W) 180
Lamp Luminous Flux(lm) 16200
Lamp Luminous Efficiency(lm/w) 95
Working Temperature(℃) -40, 80
Working Lifetime(Hour) 50000
Lamp Body Material Aluminum Alloy
IP Rating IP66
Certification CE, CQC, FCC, PSE, UL, VDE
Place of Origin Guangdong, China
Brand Name Spark LED Module Street Light
Model Number SPL-COB-180

Spark 180W COB LED Street Light 95lm/w

Spark 180W COB LED Street Light 95lm/w

Features:



  • Environmental friendly with no mercury content
  • LED as light source offer very long life as compared to conventional source
  • Wide operating voltage of 90-305V
  • Color rendering index (CRI) >75
  • Pre-wired, easy installation
  • Warm white, pure white and cool white available
  • Compact design, less weight and high cost performance
  • Adopted original integrated LED light source and professional heat dissipation system


    Main Technology Index:


    Model No.                                                      SPL-COB-180
    Rated Power180W
    LED Qty.4 PCS
    Rated Luminous Flux16,200 LM
    Luminous Efficiency95lm/W
    LED Light SourceCOB LED
    Beam Angle135°X 90°
    Correlated Color Temperature(CCT)Cool White: 5000-6300K
    Color Rendering Index(CRI)Ra>70
    Input Voltage90-305VAC
    Power Factor(PF)≥ 0.95
    Junction Temperature60°C(Ta+25°C)
    Operation Temperature -40°C--+50°C ; 10%-90%RH
    Lens MaterialOptical Glass
    IP RatingIP66
    Lifetime> 50,000h
    Product Size(mm)930 x 400 x 190

    Central
    Illumination
    and Effective
    Area    		6M Height24m×6.5m ≥108Lux
    8M Height34m×8.5m ≥60Lux
    10M Height40m×10.5m ≥39Lux
    12M Height50m×12m ≥24Lux



 Spark 180W COB LED Street Light 95lm/w

Spark 180W COB LED Street Light 95lm/w
