Home > Manufacturing & Processing Machinery > Plastic Machinery > Plastic Mixer > Plastic Mixing Machine/Plastic Mixer/Powder Blender

Plastic Mixing Machine/Plastic Mixer/Powder Blender

Name: Plastic Mixing Machine/Plastic Mixer/Powder Blender
Brand: friend
SKU: 124728243
Availability: InStock

Plastic Mixing Machine/Plastic Mixer/Powder Blender thumbnail-1

Plastic Mixing Machine/Plastic Mixer/Powder Blender photo-1

US$ 3,000 - 15,000 MOQ: 1 Set

Key Specifications

Get Latest Price

Condition:

New

Automatic Grade:

Automatic

Place of Origin:

Jiangsu, China

Contact Supplier Request Quote Chat Now

Zhangjiagang Friend Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shanghai

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Condition New

Automatic Grade Automatic

Place of Origin Jiangsu, China

Brand Name friend

Model Number srl-z, SRL-Z

Certification CE ISO

Warranty 12 Months

After-sales Service Provided Overseas service center available

Application Plastic mixer

Weight 2200-9800kg

Specifications

Plastic mixer unit
1.mixing fast.2.easily cleaning,compact structure3.steady performance.4low price.

Mixer unit

Characteristics:

It is used in mixing, stirring, drying, coloring and other technique of plastics, rubber, chemicals for daily use. It’s an ideal advanced equipment of producing plastic plate, pipe, special-shaped material and degradation plastics.

SRL-Z:

1.It’s mainly used for assorting, mixing, coloring, drying of PE, PP, PVC, etc. Also for the techiques, including drying, dehydration, etc. of engineering plastics such as ABS, polycarbonate, etc. before forming and processing, as well as in the mixing of phenolic.

2.This unit can combine hot mixing with cold mixing. The materials after hot mixing can enter into cold mixer automatically to mix and cool, exhaust remnant gas to prevent materials from blocking effectively.

Technical parameters:

SRL-Z	Heat/cool	Heat/cool	Heat/cool	Heat/cool	Heat/cool
Total capacity(L)	100/200	200/500	300/600	500/1000	800/1600
Effective capacity(L)	65/130	150/320	225/380	330/750	600/1050
Stirring speed(r/min)	650/130/200	475/950/130	475/950/100	430/860/70	370/740/50
Heating/cool method	Electric, self-friction/water
Mixing time(min)	8-12	8-12	8-12	8-15	8-15
Power(kw)	14/22/7.5	30/42/11	40/55/11	55/75/15	83/110/22
Overall dimension(mm)	*195016001800*	*458022402470*	*480026402480*	*560030003100*	*517032004480*
Weight(kg)	2200	3400	3600	6500	9800

Main Specification & Technological Parameters

Parameter	Hot Machine	Parameter	Cold Machine
Total Volume	500L	Total Volume	1000L
Effective Volume	375L	Effective Volume	640L
Once Feeding Volume	≤180kg	Once Feeding Volume	≤200kg
Production Capacity	≥1000kg/h (Take hard PVC raw material as standard
Stirring Blade	3	Stirring Blade	1
Rotary Speed of Stirring Blade	430/860r/min	Rotary Speed of Stirring Blade	110r/min
Lifting Control	Air-operated	Lifting Control	Air-operated
		Cooling Method	Water-cooling
		Cooling Water Temperature	9-15°C≤0.1Mpa
		Cooled Material Temperature	40-60°C
Mixing Time	≤ 10 min/pot	Cooling Time	≤ 10 min/pot
Power	47/67kw	Power	15kw
Appearance Size of Main Machine	(L× W× H ) 3780 00×1870×2250
Weight of Equipment	4000kg
Electric Control Cabinet	Vertical Type 1 set
Control Cabinet Size	(L× W× H ) 840× 550 × 1700 mm
Used Power Source	AC 380V 50 Hz
Used Gas Source	Compressed air 0.4—0.5 Mpa
