Small Vibrating feeder manufacture for mineral
- 5000 Set / Sets per Month
- any port in china
- T/T L/C D/P D/A
-
ZSW850 Electromagnetic Mining Vibrating Grizzly Screen Feeder Price
-
Hanging Vibrating Feeder Screw ZSW Series Vibration Feeder For Quarry Stone
-
Coal Mining Industry Vibratory Feeder Industrial And Vibrating Feeder Capacity Calculation
-
Vibratory Feeder Industrial And Vibratory Feeder Controller Price
-
Vibratory Feeder Industrial And Vibrating Feeder Capacity Calculation
-
Mining Selecting Vibratory Feeder Industrial For Sale
Product Details
Condition: | New | Application: | coal,mineral processing,building,mi | Power Type: | Electric |
Capacity(t/h): | 90-200t/h | Place of Origin: | Henan, China | Brand Name: | YinHai |
Model Number: | ZSW-960*3800 | Power(W): | 11kw | Dimension(L*W*H): | 3882*2224*2121mm |
Weight: | 3980kg | Certification: | ISO9001:2008 | Warranty: | 1year |
After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Small Vibrating feeder manufacture for mineral
Vibrating feeder in our working shop photo
Product description
Brief introduction to Vibrating feeder:
The Vibrating Feeder (Vibratory feeder) is used to transfer the large size materials and granular materials from Silo to receiving device uniformly, periodically and continuously in the production flow and to feed materials into the crusher continuously and uniformly also to screen the materials in the sandstone production line. The Vibrating Feeder is widely used to match the crushing and sieving equipments in many industries including metallurgy, coal mine, mineral dressing, building material, chemical, grinding, etc.
Working principle of Vibrating feeder
There are two eccentric shafts rotating at high speed at the same time from opposite directions, thus the strong centrifugal force is formed. The component forces of centrifugal force along the vibrating direction will always overlap each other, then counteract with that of vertical force from vibrating direction, then exciting force along single direction is formed to drive the feeder vibrate along straight line. When materials are fed into the feeder, they may be thrown up and move like Para curve, then fall down. The materials will move forward on the slope surface of the feeder.
Vibrating feeder structure drawing
Vibrating Feeder Technical Parameters:
Model | Size of funnel mm | Max feed lump size mm | Capacity t/h | Power kw | Weight t | Overall size mm |
GZD600*1800 | 600*1800 | 300mm | 30-80 | 1.1*2 | 1050 | 2200*1100*600 |
GZD800*3000 | 850*3000 | 400mm | 80-120 | 1.5*2 | 3195 | 3110*1600*1600 |
GZD960*3800 | 950*3800 | 500mm | 120-210 | 2.2*2 | 3980 | 3850*1950*1630 |
GZD1100*4200 | 1100*4200 | 580mm | 200-430 | 3.7*2 | 5570 | 4400*2050*1660 |
GZD1100*4900 | 1100*4900 | 580mm | 280-500 | 5.5*2 | 6520 | 5200*2050*1700 |
GZD1300*5200 | 1300*5200 | 650mm | 450-600 | 7.5*2 | 8200 | 5200*2350*1750 |
ZSW960*3800 | 960*3800 | 500mm | 90-200 | 11 | 3980 | 3882*2224*2121 |
ZSW1100*4900 | 1100*4900 | 580mm | 180-380 | 15 | 5320 | 4957*2500*1365 |
ZSW1300*4900 | 1300*4900 | 750 | 250*450 | 22 | 5900 | 4957*2580*2083 |
Our service
Before sale
Be a good consultant and assistant of our customer to ensure our customer's investment will be rewarded with great profit.
1.Select the right model of equopment for customer.
2.Our service engineers would be ready for service 24 hours per day.
3.We will answer your qustion any time
4.Provide training for customer's technician
During sale
Respect every customer and provide them convenience and reliability.We are devoted to help customer gain more.
1.Inspect before accept the products sent by us.
2.Assist our customer to make a constrution plan.
After sale
1.The installation and testing of equipment.
2.We would be ready for service 24 hours per day to accept your feedback .
3.we would provide maintaince if our product have problem.
Packing&Shipping
Packing :
1.Standard export containers,bare main machine, motors and small parts are packed in wooden cases..
2.If you need special package ,we can do as your requirement.
Shipping:
About 20-30 days after receipt the deposit
Our company
Zhengzhou YinHai Mining Machinery equipment Co., Ltd. is a hi-tech, engineering group. We are specialized in the research, development, and production of industrial crushing, powder grinding, mineral processing equipments and other related devices. Our products have been sold to 120 countries and areas of Southeast Asia, East Europe, South America, the Middle East and Africa etc, and more foreign markets will be promoted in future. We hold "Pursuing the YinHaiTechnology and Quality" as our management concept all the time. Relying on absorbing world leading crushing and powder processing technology, advanced management and quality control system, as well as our full efforts, YINHAI has earned high reputation among our customers.
How about the quality of our machine?
Our machine manufactured strictly according to national and international standard.
We take a test on every machine before delivery.
How about price of machine?
We can give the lowest price than market one.
We do quotation of machine as soon as possible for any custome.
Discount of machine can be given according to quantity.
How about the after-sale service of your company?
Our engineer is aviliable to installation machine overseas.
The guarantee period of our machine is one year.
Spare parts will supply at any time.
Note: Above technical parameters are just for reference, if you want to get more detailed information or if you have any trouble in selecting the suitable machine, please contact us.
