Hydraulic Lab Jaw Crusher Manufacturer
US$ 1,000 - 5,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Jaw Crusher
Application:
Construction
Payment & Shipping
Payment Methods:
Port of Shipment:
QD
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Condition
New
Type
Jaw Crusher
Application
Construction
Motor Type
AC Motor
Power(W)
5.5kw
Capacity(t/h)
200-500KG
Place of Origin
Henan, China
Brand Name
YH
Model Number
PEX100*150
Dimension(L*W*H)
Size
Weight
300kg
Certification
ISO9001:2008
Warranty
12 Months
After-sales Service Provided
No overseas service provided
Working principle of lab jaw crusher
Motor drives belt and belt pulley, makes moving jaw up and down through eccentric shaft. When the moving jaw is up, the angle between lining plate and moving jaw becomes large, and this will push moving jaw plate close to the fixed jaw plate. During this process, the material is crushed and ground, thus the crushing will be done. When the moving jaw is down, the angle between lining plate and moving jaw becomes small, the moving jaw plate will leave the fixed jaw plate on account of the effect of pulling bar and spring, and then the crushed material will be discharged from the lower opening of the crushing room. With the motor continuously rotating and the material periodically crushed and discharged by the crusher, the mass production can be realized.
