1.Application of primary stone crusher jaw crusher price at a reasonale price :
Hengrui primary jaw crusher are ideal for primary and secondary crushing. With the increase of production, our jaw crusher can greatly reduce the operating costs. And it is of reliability and flexibility. The large feed opening and force-feeding action from the inward and downward eccentric movement of the swing jaw mean that our jaw crusher can increase the capacity. The jaw has a smaller discharge setting, allowing for a higher degree of flexibility with relative equipment. Posi
2.Features of primary stone crusher jaw crusher price at a reasonale price:
1.High crushing ratio, big reduction ratio and uniform final product size;
2.Simple structure and low operation and maintenance cost;
3.Big adjustment range of the outlet can satisfy the requirement of different customers;
4.Safe and reliable lubrication system, easily changed spare parts and easy maintenance;
5. Low noise and little dust pollution.
3.Working principle of primary stone crusher jaw crusher price at a reasonale price :
The motor transmits power through belt, drives the moving jaw to do periodic motion towards the fixed jaw by the eccentric shaft. The angle between toggle plate and moving jaw plate increases when moving jaw moves. So the moving jaw moves towards the fixed jaw. The stuff will be crushed in this process. The angle between toggle plate and moving jaw decreases when moving jaw moves down, the moving jaw moves leaves fixed jaw by pulling rod and spring, the final crushed stuff will be discharged from the outlet. Firstly the machine's leather belt and wheel are driven by the electric motor, then the movable jaw begins to move up and down by the eccentric shaft, when the movable jaw move from top to bottom, the angle between fixed jaw and movable jaw becomes smaller, the materials are crushed into pieces to reach the crushing target. When the movable jaw moves from bottom to top, the angle between fixed jaw and movable jaw becomes bigger, the movable jaw plate deviates from the fixed jaw plate under the function of drag rod and spring, at this moment, the crushed materials are discharged from the bottom outlet of the crushing cavity.
