SCA140T Four axis tip over switch Accuracy0.03degrees

cartons

Specifications

Four-axis tip-over switch
1.four directions signal output
2.Accuracy0.03degrees



 SCA140T Four axis tip over switch  Accuracy0.03degrees





SCA140T is a four-axis tip-over switch(four directions switch,dip over switch, tilt switch,inclinometer switch)which is researched and produced by Shenzhen RION with high accuracy and high stability ,Its Measuring range is±85°, Four directions will output four switching signal (-x,+x,-y,+y),The switch action points and trigger delay time can be output and set through the RS232  serial communication port. It has ZERO setting function and response frequency adjustment function as well as optional Baud rate. It can be widely used in engineering mechanism field.





Features:
1:Four-axis switch with built-in Relay
2:Customers can self-set switch alarm values
3:ZERO setting function
4:DC 9~36V wide voltage power supply
5:Multi-Measuring range
6:Four channel switch signal and RS232 outpout
7:Full Metal Jacket,IP97 protection
8:Entirely industrial parts of appratus,stable and credible performance
9:Shockproof>20000g
10:Small volume,light weight
11:reverse polarity protection,over loading short circuit protection.
12:transistor drive,OC door output
13:small size(91*40*26mm)



Applications:
1:Chain Block,Hoist,Crane.
2:Aerial Platform Vehicle,lifter
3:Automatic orientation platform
4:Mining mechanism,oil-well drilling equipment
5:Security control,monitor,alarm
