Specifications
GYXTW Outdoor Aerial Optical Fiber Cable1.Outdoor Optical Fiber Cable
2.Two Steel wire
3.Aerial optical cable
merciogi
GYXTW Outdoor Aerial Optical Fiber Cable
1)GYXTW Outdoor Aerial Optical Fiber Cable Product Structure
1. Stranded
2. Loose tube
3. Light-armored
4. PE Sheathed
5. GYXTW--- Stranded Loose Tube Light-armored Cable
2)GYXTW Outdoor Aerial Optical Fiber Cable Standards
Complies with YD/T 723.1-2007, YD/T 816-2003, YDN 042-1997 standard
- Low dispersion and attenuation
- Proper design, precise control for fiber excess length and distinct stranding process render the cable excellent mechanical and environmental properties
- The armoring of corrugate steel tape make cable have nice properties of moisture resistance and crush resistance
- With small cable diameter, light cable weight, easily to lay
- Operating Temperature : -40~+60 °C
4)GYXTW Outdoor Aerial Optical Fiber Cable Information
Model No. |
Fiber Count |
Cable Diameter |
Cable Weight |
Tensile Strength (Long/Short Term) |
|
|
mm |
kg/km |
N |
APG-GYXTW |
2~12 |
8.5-9.0 |
75-80 |
600/1500 |
|
Fiber count |
Cable dia.(mm) |
Cable net weight (Kg/km) |
Min. bending radius(mm) |
Min. tensile strength(N) |
Min. crush pressure(N/100mm) |
|||
Static state |
Dynamic state |
Short term |
Long term |
Short term |
Long` term |
|||
6 and below |
10.1 |
104 |
110 |
220 |
1500 |
600 |
1000 |
300 |
8~12 |
10.6 |
114 |
110 |
220 |
1500 |
600 |
1000 |
300 |
14~24 |
11.2 |
128 |
120 |
240 |
1500 |
600 |
1000 |
300 |
