RG6 Cable Coaxial
Negotiable
MOQ: 100 Kilometers (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
China
Brand Name:
DB
Model Number:
RG6 Cable Coaxial
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
FC Fiber Optical Cables Connector With 2.0mm BootUS$ 0.1 - 0.4MOQ: 1000 Pieces -
Dongbei Cheapest High Quality Optical Fiber Cable ConnectorUS$ 0.1 - 0.4MOQ: 1000 Pieces
-
Fiber Optical Plug Fibre Optic Cable Connector TypesNegotiableMOQ: 1000 Pieces
-
ST/PC Multi Mode Simplex China Fiber Optic Connector and AdapterNegotiableMOQ: 1000 Pieces
-
ST Outdoor Fiber Fast ConnectorNegotiableMOQ: 1000 Pieces
Place of Origin
China
Brand Name
DB
Model Number
RG6 Cable Coaxial
Type
Coaxial
Number of Conductors
2
Specifications
RG6 Cable Coaxial1.Good quality with nice price
2.Manufacture ODM,OEM accept
3.RG6,11,59, drop,trunk cable
4.75 ohm telecom
RG6 Cable Coaxial
- Coaxial Cable RG6 Impedance: 75+3 Ohm
- Capacitance: 54+3pF/m
| BASIC CONSTRUCTION :(Aerial 60% coaxial cable RG6 75 Ohm) | ||||
| SHIELD SHIELD | TRI-SHIELD | QUAD-SHIELD | ||
| CONDUCTOR | MATERIAL | BC/CCS | BC/CCX | BC/CCX |
| Nom.Dia | 18AWG | 18AWG | 18AWG | |
| DIELECTRIC | MATERIAL | Foamed PE | Foamed PE | Foamed PE |
| Nom.Dia | 4.57mm | 4.57mm | 4.57mm | |
| SHIELD | MATERIAL | AL Foil+AL Braiding | AL-Foil+Braiding of AL +AL-Foil |
(AL-Foil+Braiding of AL)*2 |
| COVERAGE | 40%-90% | 40%-90% | 40%/60% | |
| METERIAL | PVC/PE | PVC/PE | PVC/PE | |
| JACKET | Nom.Thick. | 0.80mm | 0.80mm | 0.86mm |
| Nom.Dia | 6.91mm | 6.91mm | 6.91mm | |
| RG6 Cable Coaxial BASIC CHARACTERISTICS | 75 | ||
| Nominal Impedance | 85 | ||
| Nominal Velocity of Propagation | 50 | ||
| Sparker Test (VAC) | 4000 | ||
| SRL(Db) | 20 | 20 | |
| Attenuation | Frequency(MHz) | Maximum(Db/100ft) | Maximum(Db/100m) |
| 5 | 0.58 | 1.9 | |
| 55 | 1.6 | 5.25 | |
| 187 | 2.85 | 9.35 | |
| 300 | 3.55 | 11.64 | |
| 450 | 4.4 | 14.43 | |
| 600 | 5.1 | 16.73 | |
| 750 | 5.65 | 18.54 | |
| 865 | 6.1 | 20.01 | |
| 1000 | 6.55 | 21.49 | |
| 1450 | 7.98 | 26.16 | |
| 1800 | 8.64 | 27.73 | |
| 2100 | 9.5 | 31.15 | |
| 2250 | 10 | 34.03 | |
| 3000 | 11.4 | 37.5 | |
| Other Type | RG6 Dual | RG6 with Messenger | RG6 Dual with messenger |
