Help Center10ml-2000ml DY1200B Semi Automatic Blowing Machine,PET Bottle Making Machine,hot Sale
Related Products
-
Pet Bottle Blowing Machine,5L Blowing Moulding Machine,mineral Water Bottle Making Machine,US$ 5,500 - 5,800MOQ: 1 Set -
Hot!!!!!!!5L Blowing Moulding Machine,mineral Water Bottle Making Machine,US$ 4,800 - 5,200MOQ: 1 Set
-
Semi-automatic PET Blow Moulding Machine,small Pet Bottle Making Machine,pet Blow Molding Machine,US$ 4,100 - 4,500MOQ: 1 Set
-
5L Blowing Moulding Machine,mineral Water Bottle Making Machine,NegotiableMOQ: 1 Set
-
Easy Operate Semi-automatic PET Blow Moulding Machine,small Pet Bottle Making Machine,pet Blow Molding Machine,US$ 24,920 - 24,920MOQ: 1 Set
Specifications
This machine is suitable for blowing PET bottles of various shapes, volume from 100 ml to 2000 ml,mineral water,soda bottles etc
i.Machine specification
DY 1200B SEMI Automatic Bottle blowing machine is suitable for blowing PET bottles of various shapes, volume from 100 ml to 2000 ml, wide application for blowing mineral water bottles, soda bottles, cola bottles..
1,New double crank four pull-up bar clamping structure, cross balance fixed slide
2,Sealing, stretch adapts parallel bars (CIS) design, combined, good for products molding
3,Advanced gas path design, single, dual air intake can be; low-pressure mechanical clamping, sealing, stretching; high pressure blowing molding
4,Programmable PLC controller automatically control, microcomputer touch screen convenient operation
5,Bottle embryo heated by infrared, controllable constant pressure control, so as to achieve the best blowing precision
ii.Machine Technical data and configuration
DY-1200B technical data and configuration(standard type) |
|
||
theory output |
according to bottle shape |
1000pcs/h(600ml) |
|
product Max volum |
according to mold cavities |
1500ml(2cavities) |
|
Mold |
2 cavities |
2cavities/1500ml |
|
product max diameter |
95MM |
|
|
product max height |
320MM |
|
|
mould area |
520*350MM |
|
|
mold thickness |
200MM |
|
|
move mold distance |
120MM |
|
|
max stretching distance |
420MM |
|
|
lock mold strength |
480KN |
|
|
power |
power |
220~380V,3phase 50~60Hz |
|
heating power |
12KW |
|
|
operation air pressure |
0.8Mpa |
|
|
air blowing pressure |
3.0Mpa |
|
|
main machine size |
length*width*height |
1650*610*1700MM |
|
oven size |
length*width*height |
1800*610*1400MM |
|
main machine weight |
800Kg |
|
|
oven weight |
300Kg |
|
|
Auxiliary equipment |
high pressure air compressor 1set |
0.7M3/3.0Mpa/11Kw |
|
|
|||
air filter 2pieces |
3.0m3/3.0Mpa |
|
|
