Hot!!!!!!!5L Blowing Moulding Machine,mineral Water Bottle Making Machine,

Name: Hot!!!!!!!5L Blowing Moulding Machine,mineral Water Bottle Making Machine,
Brand: DIANYA
SKU: 124464067
Availability: InStock

US$ 4,800 - 5,200 MOQ: 1 Set

Key Specifications

Condition:

New

Application:

Bottle

Plastic Processed:

PET

Taizhou Huangyan Dianya Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

ningbo

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Application Bottle

Plastic Processed PET

Blow Moulding Type Stretch Blow Moulding

Automatic No

Place of Origin Zhejiang, China

Brand Name DIANYA

Model Number DY-500 pet bottle blowing machine

Specifications

pet bottle blowing machine
1.high quality
2.excellent after-sale servies
3.easy to operate

1.pet bottle blowing machine

Suitable for blowing CO2 bottles, mineral water bottles, pharmaceutical bottles, oil bottles, cosmetic bottles and hot filling bottles

Specifications

1.mineral water bottle, oil bottle, juice bottle
2.cavity: 1,2,3,4
3.Micro PLC
4.two linkage clamping
5.infra-red preheater

Characteristics:

1. Two-bar linkage clamping design increases clamping force.

2. We adopt the high technology of Micro PLC controller on this bottle blowing machine.

3. This bottle blow molding machine works properly and stably.

4. Infra-red heater guarantees equilibrium temperature inside the preform and on its surface.

2.parameter

DY-500TYPE Technical data and Machine configuration(standard type)
Theory output	according to bottle type	200pcs/h(10000ml)
product max volume	according to mold cavity	10000ml(1cavity)
Mold	1 cavity	10000ml
	product Max diameter	95MM
	product max height	320MM
	mold area	520*350MM
	mold thickness	180MM
	mold moving distance	20MM
	max stretch distance	420MM
	lock mold power	480KN
power	power	220~380V
	heating power	12KW
	operating power	0.8Mpa
	air blowing pressure	3.0Mpa
main machine size	lengthwidthheight	18506101700MM
oven size	length* width* height	18006101400MM
main machine weight	800Kg
oven weight	300Kg
Our machine all Electrical components use famous standard Universal Products
