HDMI extender 60m CAT5e/6 HDMI extender over utp cable

Name: HDMI extender 60m CAT5e/6 HDMI extender over utp cable
Brand: Protech
Price: USD $12.99 - 40 / Piece

FOB Price

USD $12.99 - $40 / Piece

50 Pieces(Min.Order)

Supply Ability 50000 Piece / Pieces per Month
Port shenzhen
Payment Terms:T/T L/C D/P D/A

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Details

Brand Name:

Protech

Model Number:

PET60E (HDMI Extender)

Place of Origin:

Guangdong, China

Product Description

HDMI extender 60m CAT5e/6 HDMI extender over utp cable

Product Description

Introduction

This HDMI Extender by CAT-5e/6 uses two pieces of CAT-5e/6 cables to extend the HDTV display up to 50 merters for 1080p while using CAT-6 cable. It not only breaks the limitation of the HDMI cable transmission length but also CAT-5e/6 has more flexibility and convenience in cable construction.

It is equipped with HDMI (high definition multimedia interface) connectors and is capable of supporting DVI (digital visual interface) equipment when used with an HDMI to DVI Adapter, providing greater flexibility and options when integrating several home theater components.

E60 offers solutions for residential consumers: HDTV retail and show site, HDTV, STB, DVD and Projector factories, noise, space and security concerns, data center control, information distribution, conference room presentation, school and corporate training environments.

BENEFITS

1) The length of HDMI cable is fixed and unchangeable after it is produced. Because the HDMI connector can only be soldered or terminated by the professional workers in factory, the users can not reduce or increase by themselves. However CAT-5e/6 cables are available everywhere and be processed easily by the user or installer.

2) Because the header of the long HDMI cable is big, using it must in hidden method. What's more, it is not easy to bend the HDMI cable and to pull it through the in-wall tube or tray. However, CAT-5e/6 cable has no such problems.

3) Using E60, the transmission distance can be up to 50 meters for 1080p using CAT-6 cable. For the general HDMI cables, they must be customized when the length is over 10 meters.

Features

This kind of the HDMI Extender have many features that enable them to perform in a superior manner. Among those features you will find:

* One pair as a full functional module, no need of setting.

* CAT-5e/6 cable can substitute HDMI cable to achieve long distance transmission.

* Follow the standard of IEEE-568B.

* Transmission distance can be up to 60 meters for 1080p, 120meters for 1080i, using CAT-6 Cable.

* Auto-adjustment of feedback, equalization and amplify, the user does not need to care about the length of the cable.

* Compact size.

* Signaling rates up to1.65Gbps in support of 1080P display.

Parameters

Signal Inputs/Output
Input Video Signal	0.5 -1.0 volts p-p
Input DDC Signal	5 volts p-p (TTL)
Maximum Single Link Range	1920X1200, 1080P
Output Video	HDMI 1.2a
Video format supported
DTV/HDTV	1080P/1080i/720P/576P/480P/576i/480i
Transmission distance
CAT-6 cable	50M for1080p
CAT-6 cable	100M for480p
Resolutions(HDTV)
Interlaced(50&60Hz)	480i,576i,1080i
Progressive(50&60Hz)	480p,576p,720p,1080p
Mechanical
Size(W-H-D)	45mmW x 25mmH x 81mmD
Weight(Net)	0.246KGs
Power Consumption	5Watts (max.)
Warranty
Limited Warranty	1 Year Parts and Labor
Environmental
Operating Temperature	0°C to +70°C
Operating Humidity	10% to 85 % RH (no condensation)
Storage Temperature	-10°C to +80°C
Storage Humidity	5% to 95 % RH (no condensation)
Power Requirement
External Power Supply	5V DC@2A
Regulatory Approvals
Converter Unit	FCC,CE
Power Supply	CE,FCC
Accessories Adapter
AC Power Adapter	US standard, UK standard and so on
User Manual

Package contain

1) Main unit NO. 1 Sender

2) Main unit NO. 2 Receiver

3) User Manual

4) Power Adaptet

About us

As a specialized independent supplier of HDMI products, Protech Electronics & Technology Limited focuses on high quality image process technology and application design,owns perfect production lines and innovates on technical route continually to provide the best solutions for home media, especially for HD source connection,experienced OEM, ODM production

Our Services

FAQ

Q1: Are you a manufacturer or trading company?

A1: yes, we are manufacturer. We located in Shenzhen, China. And the FOB Shenzhen port is Yantian/Shekou.

Q2: Can I customized my product in your factory?

A2: Sure, we offer OEM and ODM service.

Q3: Do your product comes with a warranty?

A3: yes, 1 year parts and labor.

Q4: Can you give me a discount?

A4: Yes, the discount comes with different quantity. If the order quantity exceed 50pcs, we will give you a discount, if exceed 100pcs, another discount, if exceed 300pcs, 500pcs, 1000pcs, 2000pcs..., the more quantity your order, the lower price you will get.

Q5: What information should I provide if i want to get a quotation?

A5:

For our product with totally our design	Item name, order quantity, shipping term(EXW/FOB etc)
For OEM items	Item description, detailed spec, color, package content, order quantity, shipping terms, photo

Q6: How many days will the sample be available? And what about the mass production?

A6: sample will be sent out within 3 days after sample cost is settled and confirmed. For mass production, ready in 1-3 days with stock, 1-3 weeks for those without stock.

Q7: what is your inspection procedure?

A7: 1st inspection: when the raw material is sourced, we will have a 100% inspection.

2nd inspection: during production, we will inspect goods randomly

3rd inspection: after production is finished. Our QC department will choose 10-50% completed goods for inspection. The inspection percent depends on the order quantity!

Q8: how do you ship the goods?

A8: by sea, by air, by courier(DHL/UPS/FedEx/TNT etc)

Contact Us

Shenzhen Protech Electronics & Technology Limited: Contact nameKingsley Pang; Phone86-755-89541912; AddressNO.6 Baofu Road, Shangmu Gubaolai Industrial Park, Pinghu, Longgang District, Shenzhen, China Shenzhen,Guangdong
