Automatic Trimming High-precision Cross Cutting Machine

Automatic Trimming High-precision Cross Cutting Machine photo-1
US$ 15,000 - 16,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Product Type:
Other, paper cross cutting machine
Processing Type:
Cutting Machine
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo/Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Product Type Other, paper cross cutting machine
Processing Type Cutting Machine
Place of Origin Zhejiang, China
Brand Name BEST
Model Number DJF1100
Voltage 220V/380V
Power(W) 5.5KW
Dimension(L*W*H) 2950*1320*1500mm
Weight 1500kg
Certification CE
Warranty 1 Year
After-sales Service Provided Engineers available to service machinery overseas

Automatic Trimming High-precision Cross cutting Machine

Performance and Characteristics
This machine is suitable for horizontal and vertical cutting rolling materials such as, chrome paper, coated paper and kraft paper, etc. It's much more suitable for production of paper making and paper process industry.

Adopts pneumatic automatic materials loading system with much easy operation and convenience.
Adopts down-up recurrent cutting with orderly finished products and without water caltrop; Meantime, it can be used for horizontal cutting and vertical cutting at one time.
With PLC touch screen for electrical system section. Frequency converter timing system combined with servo motor so that this machine can be synchro operation.
It has the functions of high-precision of cutting, high speed, etc. Pneumatic structure combined with micro-computer control be adopted for transmission section, making it become much more steady operation.
It has the function of automatic stacking which is in order. Photoelectric auto tracing subtense system.

Main Technical Parameters

Model DJF-1100 DJF-1300
Max width 1100mm 1300mm
Max diameter of unwinding φ1400mm φ1400mm
Cutting length 200-1200mm 200-1200mm
Speed 10-140times/min 10-140times/min
Precision ±0.2mm ±0.2mm
Thickness scope 80-500g/m2 80-500g/m2
Height of stacking Max.1200mm Max.1200mm
Total power 8.5kw 9.5kw
Weight 3800kg 4500kg
