Home > Products > Laser machine series > Laser wood cutting Machine
Laser wood cutting Machine
- 100 Set / Sets per Month
- Guangzhou
- T/T
Product Details
Laser Type: | CO2 | Applicable Material: | Wood | Cutting Area: | 1970*1250*1300mm |
Cutting Speed: | 0-40000mm/min | CNC or Not: | Yes | Cooling Mode: | Water Cooling |
Control Software: | CORELDRAW, PHOTOSHOP, AUTCAD/CAM | Graphic Format Supported: | AI, BMP, DST, DWG, DXF, DXP, LAS, PLT, Other | Place of Origin: | Guangdong, China |
Brand Name: | Myteck | Model Number: | MT-1380 |
Product Description
Machine configuration
Parts Name | Description | Quantity |
Software. and Control | Taiwanlaser cutting system and control system | One |
Guide Rail | High-speed adjustable guide rail imported from Korea | Three |
Motor | Step motor imported from Japan | Two |
Laser power supply | Chengdu laser power supply | One |
Belt | Belt imported from American | Three |
Lens | Lens imported from American | Four |
Cooling Box | Cooling box (3000 type) for laser cutter | One |
Induced Draft Fan | Centrifugal induced draft fan | One |
Air Pump | Hailea electromagnetic air compressor | One |
Laser Tube | Chengdu laser tube | One |
Work table | Knife shape | One |
Chassis | Chassis Welding of cold rolled plate | One |
Technical Parameter
Product model | MT-1380 |
Laser power: | 60W/80W/100W/130W/150W |
Cutting scope: | 1300mm*800mm |
Laser Types | CO2 sealed glass tube laser/ CO2 metal tube laser, water-cooled, 10.6μm |
| 0-100% software setting |
Precision of Positioning | ≤0.01mm |
Max. Width of work piece: | 1300mm |
Working Voltage | 220±10% 50HZ |
Max. Length of work piece: | infinity |
Figure format | AL, DST, PLT, BMP, DXF |
Supporting software | CORELDRAW, PHOTOSHOP, AUTCAD/CAM |
Cutting depth (acrylic): | 0.1-20mm(at the speed of 8mm/sec) |
Linear speed: | marking speed 50000mm/min |
cutting speed 0-40000mm/min | |
Laser type | CO2 sealed of glass laser |
Locating accuracy | ≤ 0.01mm |
Cooling system: | water cooling |
Electric power: | 220V/50Hz/10A |
Packing Dimension (lengthXwidthXheight): | 1970*1250*1300mm |
Gross Weight | 400KG |
--------------------
Guangzhou Myteck Machinery Co., Ltd represents a good Chinese laser equipment factory China on international market. We supply good quality and all categories of laser equipment, including cutting machines, laser engraving machines, laser marking machines, computerized bending machines and knife mold machines.
We take care of your demand and your investment and we offer caring service by good communication.
Contact Us
Please feel free to consult me and your inquiry is welcome.
Allan Yao
Mobile: 0086-13822275431
Email: myteck @126.com
Contact Us
- Guangzhou Myteck Machinery Co., Ltd.
- Contact nameLouisa Wang
- Phone0086-20-32012042
- Address18-24 Tianhe East Road, Tianhe District, Guangzhou, China Guangzhou,Guangdong
