1. Main configuration of Fiber laser bed: | |
Model |
XGY-FM3015 |
Fiber Laser source |
Raycus 500W/ |
Transmission system |
Taiwan Hiwin Ball-screw |
Speed Reducer |
Taiwan |
Motor |
Servo motor: SANYO from Japan |
Laser Head |
Components and technology from Germany, Assembled in China |
System |
From Shanghai Jiao Tong University Lab |
2. Cutting thickness:
Items HS-M3015C Stainless steel (N2) 3mm
Stainless steel (O2) 6mm
Carbon steel (O2) 6mm
Galvanized steel (O2) 3mm
3. Techinical Parameters: MT-FM3015
Working area (L*W) |
3000×1500mm |
X-axis running area |
1500mm |
Y-axis running area |
3000mm |
Z-axis running area |
120mm |
X/Y axis Repeated Position Precision |
±0.05mm |
Max. Running Speed |
45m/min |
Max. accelerated speed |
0.5G |
Machine weight |
4000Kg |
Max. Load on working table |
500kg |
Phase |
Triphase |
Voltage |
380V |
Frequency |
50Hz/ 60Hz |
Applicable Industry: Metal cutting, manufacturing of electrical switches, elevator manufacturing, household appliances manufacturing, kitchenware manufacturing, processing tools, and other machinery manufacturing and processing industries.
Packaging and Shipping
Our service
Guangzhou Myteck Machinery Co., Ltd represents a good Chinese laser equipment factory on international market. We supply all categories of good quality laser equipment, including laser cutting machines, laser engraving machines, laser marking machines, computerized bending machines and cutting die machines.
Contact Us
Please feel free to consult me and your inquiry is welcome.
Allan Yao
Mobile: 0086-13822275431 (wechat or what's app)
Email: myteck at
