Home > Manufacturing & Processing Machinery > Laser Equipment > Laser Cutting Machine > Abric Laser Cutting Machine

Abric Laser Cutting Machine

Name: Abric Laser Cutting Machine
Brand: Myteck
SKU: 124337705
Availability: InStock

US$ 2,000 - 10,000 MOQ: 1 Set

Key Specifications

Get Latest Price

Condition:

New

Laser Type:

CO2

Cutting Area:

1600mm*800mm

Contact Supplier Request Quote Chat Now

Guangzhou Myteck Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Guangzhou

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Condition New

Laser Type CO2

Cutting Area 1600mm*800mm

Cutting Speed 0-40000mm/min

CNC or Not Yes

Cooling Mode Water Cooling

Control Software Taiwan laser cutting system and control system

Graphic Format Supported AI, BMP, DST, DXF, DXP, LAS

Place of Origin Guangdong, China

Brand Name Myteck

Model Number MT-D1680

Certification CE, ISO

After-sales Service Provided Engineers available to service machinery overseas

CO2 double-head high-speed laser cutting & engraving machine is developed as required by customers. It combines site production operation to completely develop the movement control performance and laser processing effect. With a special interactive design, it realizes free shift of double laser ends even is offline. Its cutting effect and doubled processing efficiency definitely feature cost saving and production promotion. It leads the position change of laser head by means of motor and belts or screw driving to achieve the laser cutting function. In addition, it can easily design graphs by means of computer, with high cutting precision and rapid speed.

It uses the stepping motor imported from Japan as the driving unit and X and Y axle three guide ways imported from Korea plus the laser lens imported from America, which can completely activate precision and speed.

Machine configuration

Parts Name	Description	Quantity
Software. and Control	Taiwan laser cutting system and control system	One
Guide Rail	High-speed adjustable guide rail imported from Korea	Three
Motor	Step motor imported from Japan	Two
Laser power supply	China laser power supply	Two
Belt	Belt imported from American	Four
Lens	Lens imported from American	Five
Cooling Box	Cooling box (3000 type) for laser cutter	Two
Induced Draft Fan	Centrifugal induced draft fan	One
Air Pump	Hailea electromagnetic air compressor	One
Laser Tube	Chengdu laser tube	Two
Work table	Honeycomb	One
Chassis	Chassis Welding of cold rolled plate	One

Technical Parameter

Product model	MT-D1680
Laser power:	60W/80W/100W/130W/150W
Cutting scope:	1600mm*800mm
Laser Types	CO2 sealed glass tube laser/ CO2 metal tube laser, water-cooled, 10.6μm
Laser Energy Contro	0-100% software setting
Precision of Positioning	≤0.01mm
Max. Width of work piece:	1600mm
Working Voltage	220±10% 50HZ
Max. Length of work piece:	infinity
Figure format	AL, DST, PLT, BMP, DXF
Supporting software	CORELDRAW, PHOTOSHOP, AUTCAD/CAM
Cutting depth (acrylic):	0.1-20mm(at the speed of 8mm/sec)
Linear speed:	marking speed 50000mm/min
Linear speed:	cutting speed 0-40000mm/min
Laser type	CO2 sealed of glass laser
Locating accuracy	≤ 0.01mm
Cooling system:	water cooling
Electric power:	220V/50Hz/10A
Packing Dimension (lengthXwidthXheight):	266016001200mm
Gross Weight	500KG

-------

Guangzhou Myteck Machinery Co., Ltd represents a good Chinese laser equipment factory China on international market. We supply good quality and all categories of laser equipment, including cutting machines, laser engraving machines, laser marking machines, computerized bending machines and knife mold machines.

We take care of your demand and your investment and we offer caring service by good communication.

Please feel free to consult me and your inquiry is welcome.

Allan Yao
Mobile: 0086-13822275431
Email: myteck @126.com
