Help CenterHG219 Tube Making Machinery
Related Products
Specifications
Commodity: Tube Making MachineryIt is designed to produce pipe of OD 89mm-219mm and corresponding rectangle and square tube
Commodity: Tube Making Machinery For HG 219
I. Summary
ERW219 pipe making machine is designed to produce welded pipes of OD 89mm(3)-219mm(8 ) and wall thickness 2.3mm-9.0mm, as well as corresponding square and rectangle tube. After we absorbed advanced pipe making technology at home and abroad, our innovative production line and each single unit of the production line are not only economical but also practical. The complete production line adopts ZTF technology developed by our company when producing circle pipe. By means of ZTF technology, the customer shall reduce 60% expense on tooling and improve production effiency and create more economic benefit.
II. Basic Technical Information:
1. Products
Pipe OD: 89mm-219mm Thickness: 2.3mm-9.0mm
Square tube: Max 175mm×175mm, 250mm×150mm
Thickness: 2.3mm-7.0mm
Length: 6 -12m Length Tolerance: ±3mm
2. Raw Material:
Material: Mild steel coil
3. Tube mill
Production Speed: 10-50 m/min
Direction : From left to right or decided by your side.
III. Flow Chart
Uncoiling→Shear & butt welding→Cage loop→Forming →HF welding →Removing & outsied Bead →Cooling →Sizing →Cuttingoff → Conveying →Downloading → Packing →Warehousing
Remark:
To protect confidential information, Here only show basic parameters. Detailed parameter will be known in the quotation list or negotiate with customer.
