Portable Gasoline Welding Generator(SHW190/210/300-B)

FOB Price

Negotiable / Set

100 Sets(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Zhejiang, China	Brand Name	ANDITIGER,ANDI,ELEFUJI,ASTRA KOREA,ELEMAX
Model Number	SHW190/210/300-B	Output Type	AC Single Phase
Speed	3600	Frequency	50/60
Rated Power	2.0KW	Rated Voltage	220V
Rated Current	9A

1) Gasoline welder generator
2) 4-Stroke,single cylinder , Air-cooled,
3) 50/60hz
4) 1 year warranty

Welding Generator

• ANDI-190 welding generator is an intermediate frequency (720HZ)welding machine with up to 190A current output.

• Powered by self-made reliable gasoline engine,it is good for field welding which needs high efficiency and quality,

and it is number one silent welding generator

Technical Parameters

NAME	ITEM	SHW190	SHW210R	SHW300E
Engine	Engine Model	GX390		GX670
	Type	4-stroke,OHV,1cylinder		4stroke,OHV, 2cylinders
	Displacement(cc)	389		670
	Bore*Stroke(mm)	88*64		77*72
	Cooling system	Air cooling
	Ignition system	Transistorized magneto ignition
	Start system	Recoil/Electric		Electric
Generator	Rated voltage(V)	220(AC)		220(DC)
	Rated frequency(HZ)	50/60		60
	Rated current	9.1A(AC)	15A(AC)
	Rated output 50HZ	5.0KVA(AC)	5.0KVA(AC)	5KW(DC)
	Rated output 60HZ	5.0KVA(AC)	5.0KVA(AC)
	Rated power factor	cos φ=1.0
	Phase	Single
	Type	2-pole,rotating type		24-pole,rotating type
DC Welder	Rated Max .current(A)	180	200	300
	Load voltage(V)	27.2	28	32
	Current range(A)	50-180	60-190	60-300
	Max.current duty cycle(%)	20	32	20
	Applicable welding rod diameter(mm)	2.5-5.0	2.5-5.0	2.5-6.0
	Rated Revolving Speed(r/min)	3600
	No-load voltage(A)	70	52	82
	Idle control	Automatic
	Rectifier type	Six phase half wave rectifier		Three phase full wave rectifier
Other	Fuel tank capacity(L)	13	27.5	23
	LengthWidthHeight(mm)	690510520	690535540	953617622
	Net weight(kg)	86	88	180
