5kw Electric Gasoline Welding Machine Generator With CE SONCAP Quality Choice
US$ 450 - 550
MOQ: 100 Sets
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
ANDITIGER,ANDI,ELEFUJI,ASTRA KOREA,ELEMAX
Model Number:
SHW190/210/300-B
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo Port
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
5kw ELEMAX Silent Gasoline Welding Generator(SHW190/210/300-A) Quality ChoiceUS$ 450 - 550MOQ: 100 Sets -
Gasoline Welder ELEMAXNegotiableMOQ: 100 Sets
-
5kw Electric Gasoline Welding Generator With CE SoncapUS$ 480 - 550MOQ: 50 Pieces
-
5kW HONDA Engine Welding Generator GX390US$ 520 - 599MOQ: 50 Pieces
-
Honda Welding Generator 5KVA Welder Generator Portable Welder GeneratorUS$ 445 - 602MOQ: 10 Pieces
Place of Origin
Zhejiang, China
Brand Name
ANDITIGER,ANDI,ELEFUJI,ASTRA KOREA,ELEMAX
Model Number
SHW190/210/300-B
Output Type
AC Single Phase
Speed
3600
Frequency
50/60
Rated Power
5KW
Rated Voltage
220V
Rated Current
9A
Specifications
1) Gasoline welder generator2) 4-Stroke,single cylinder , Air-cooled,
3) 50/60hz
4) 1 year warranty
Product Name
5kw Electric Gasoline Welding Machine Generator with CE SONCAP
• ANDI-190 welding generator is an intermediate frequency (720HZ)welding machine with up to 190A current output.
• Powered by self-made reliable gasoline engine,it is good for field welding which needs high efficiency and quality,
and it is number one silent welding generator
Technical Parameters
| NAME | ITEM | SHW190 | SHW210R | SHW300E | |||
| Engine | Engine Model | GX390 | GX670 | ||||
| Type | 4-stroke,OHV,1cylinder | 4stroke,OHV, 2cylinders | |||||
| Displacement(cc) | 389 | 670 | |||||
| Bore*Stroke(mm) | 88*64 | 77*72 | |||||
| Cooling system | Air cooling | ||||||
| Ignition system | Transistorized magneto ignition | ||||||
| Start system | Recoil/Electric | Electric | |||||
| Generator | Rated voltage(V) | 220(AC) | 220(DC) | ||||
| Rated frequency(HZ) | 50/60 | 60 | |||||
| Rated current | 9.1A(AC) | 15A(AC) | |||||
| Rated output 50HZ | 5.0KVA(AC) | 5.0KVA(AC) | 5KW(DC) | ||||
| Rated output 60HZ | 5.0KVA(AC) | 5.0KVA(AC) | |||||
| Rated power factor | cos φ=1.0 | ||||||
| Phase | Single | ||||||
| Type | 2-pole,rotating type | 24-pole,rotating type | |||||
| DC Welder | Rated Max .current(A) | 180 | 200 | 300 | |||
| Load voltage(V) | 27.2 | 28 | 32 | ||||
| Current range(A) | 50-180 | 60-190 | 60-300 | ||||
| Max.current duty cycle(%) | 20 | 32 | 20 | ||||
| Applicable welding rod diameter(mm) | 2.5-5.0 | 2.5-5.0 | 2.5-6.0 | ||||
| Rated Revolving Speed(r/min) | 3600 | ||||||
| No-load voltage(A) | 70 | 52 | 82 | ||||
| Idle control | Automatic | ||||||
| Rectifier type | Six phase half wave rectifier | Three phase full wave rectifier | |||||
| Other | Fuel tank capacity(L) | 13 | 27.5 | 23 | |||
| Length*Width*Height(mm) | 690*510*520 | 690*535*540 | 953*617*622 | ||||
| Net weight(kg) | 86 | 88 | 180 | ||||
