Home > Products > 5050 SMD LED Module > 12V IP65 waterproof 2 pcs 5050 SMD injection led module

12V IP65 waterproof 2 pcs 5050 SMD injection led module

FOB Price

USD $0.23 - $0.27 / Piece

1000 Pieces(Min.Order)

Product Details

Model Number:	SZ-45122X-50	Emitting Color:	Other, warm white/nature white/cool white/R/G/B/Y	Luminous Flux(lm):	40lumen
Optical Attenuation(%):	3%	Power:	Other, 0.48watt	Color Rendering Index(Ra):	75
Color Temperature:	2700-12000k	Operating Temperature(℃):	-20, 60	Storage Temperature(℃):	-50, 60
Place of Origin:	Guangdong, China	Brand Name:	singsunled	Certification:	CE

Features:

1. Adopt TOP 5050 SMD LED, no light spot, with a low lumen recession and good consistency.

2. With a low power consumption and high lumen value, a long life-span, maintenance-free.

3. With a plastic injection technique for outer cover, this unique structure grants a better cooling effect.

4. IP Rate: IP65, waterproof.

5. DC 12V low voltage input, reliable and safe.

6. Adopt series-parallel connection circuit, 20pcs for 1 string, each module could be singled out.

Product Specifications:

LED Type	5050 SMD LED
LED BRAND	Epistar chip from Taiwan
Viewing Angle	≥120°
Luminous Flux(lm)	40 LM
LED Qty	2 pcs
Life Span	50,000 H
Working Voltage	DC12V
Consumption	0.48 W
Driving Method	constant voltage
Stand Length In Serial Connection	20pcs
Maximum Length In Serial Connection	≤20pcs
Shell	Milk white PVC
Dimension	48155.5 mm
Available Color	W/WW/CW/R/G/B/Y
Certification	CE&ROHS
Working Temperature	-20℃ —— +60℃
Store Temperature	-50℃ —— +60℃
IP Degree	IP65

Package:

Every 20 pcs per a string, every 5 string in an anti-static bag, 3000 pcs per a carton box. Carton size: 50*35*31.5 cm.

Net Weight: 9 g/pc; 180 g/string; 28kg/carton.

Dimension Diagram(mm):

Connection Diagram:

Application:

1. Backlight of giant signage ,channel letter and lighting box.

2. Marine signal and task lighting.

3. Architectural outdoor lights.

CE & RoHS Certifications:

Exhibition Pictures:

Russian REKLAMA 2014 (Time: 23-36, September, 2014. Booth No: FC144)

2014 Hong Kong International Lighting Fair Autumn Edition ( Time: 27-30 October, 2014. Booth No: CR-A32)

2014 GZ& Shanghai International Lighting EXPO

Shenzhen Singsunled Co., Ltd.: Contact nameTracy Gao; Phone86-755-28089078; Address2F, No. 5 of Xinggong 2nd Road, Hongxing Village, Gongming Street, Guangming New District Shenzhen,Guangdong
