High Quality 2835 Smd 0.5w Led Module 45lm Led Module With Lens

High Quality 2835 Smd 0.5w Led Module 45lm Led Module With Lens thumbnail-1
High Quality 2835 Smd 0.5w Led Module 45lm Led Module With Lens thumbnail-2
High Quality 2835 Smd 0.5w Led Module 45lm Led Module With Lens thumbnail-3
High Quality 2835 Smd 0.5w Led Module 45lm Led Module With Lens thumbnail-4
High Quality 2835 Smd 0.5w Led Module 45lm Led Module With Lens photo-1
High Quality 2835 Smd 0.5w Led Module 45lm Led Module With Lens photo-2
High Quality 2835 Smd 0.5w Led Module 45lm Led Module With Lens photo-3
High Quality 2835 Smd 0.5w Led Module 45lm Led Module With Lens photo-4
US$ 0.1 - 0.25 MOQ: 1000 Pieces
Key Specifications
Get Latest Price
Model Number:
STF-T1
Chip Material:
Other, Epistar
Emitting Color:
Other, WW CW PW
Contact Supplier Request Quote Chat Now
Shenzhen Singsunled Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Model Number STF-T1
Chip Material Other, Epistar
Emitting Color Other, WW CW PW
Luminous Intensity 2000-2500MCD
Luminous Flux(lm) 45LM
Optical Attenuation(%) 2
Power Other, 0.5W
Power Dissipation 0.5W
Color Rendering Index(Ra) 85
Color Temperature 2900-12000K
Operating Temperature(℃) -50, 60
Storage Temperature(℃) -20, 60
Place of Origin Guangdong, China
Brand Name Singsun
Certification CE

High quality 2835 smd 0.5w led module 45lm led module with lens





Product Description



Product Specifications:



LED Type

2835 SMD LED

LED BRAND

Epistar chip from Taiwan

Viewing Angle

165-170°

Luminous Flux(lm)

45LM

LED Qty

1 pcs

 Life Span

50,000 H

Working Voltage

DC12V

Consumption

0.5watt

Driving Method

constant current

Stand Length In Serial Connection

50pcs

Maximum Length In Serial Connection

≤50pcs

Shell

white ABS

Dimension

30*17*6.5 mm

Available Color

W/WW/CW

Certification

CE&ROHS

Working Temperature

 -20℃ —— +60℃

Store Temperature

 -50℃ —— +60℃

IP Degree

IP65



Dimesion Diagram(mm):







Features:



1. Adopt TOP 2835 SMD LED, no light spot, with a low lumen recession and good consistency.

2. With a low power consumption and high lumen value, 35LM/led, a long life-span, maintenance-free.

3. With a plastic injection technique for outer cover, this unique structure grants a better cooling effect. UL 94V0 ABS.

4. DC 12V low voltage input, constant current drive method, reliable and safe.

5. Adopt series-parallel connection circuit, 50pcs per string, each module could be singled out.

6. Viewing angle: 165-170°.

7. Three years warranty.



Application:



This product is applicable for 3-20cm glowing character, advertisement board, light box or local lighting.











Packaging & Shipping



50 pcs per a string, 100pcs per bag, 5000 pcs per a carton box.  Carton size: 50*35*31.5 cm.

Net Weight: 4.5 g/pc;  225 g/string;  24kg/carton.



High quality 2835 smd 0.5w led module 45lm led module with lens





Our Services



 1. For all your inquiries about us or our products, we will reply you in detail within 24 hours.
2. We own well-trained and passionate sales & after-sale services who can speak fluent English language.
3. We offer OEM services. Like print your own logo on product or customize the retail box packing ,etc.
4. We have very experienced R&D engineers and we have strong ability to do ODM projects.


Company Information



 Shenzhen Singsun LED Co., Ltd, was founded in 2009, specialized in development & production of LED lighting products.We are engaged in research and development, production, marketing and service. Singsun LED has been one of the most excellent manufacturers in the LED field in Shenzhen, China.
We have dedicated in providing high quality advertisment lighting,perfect commercial lighting solution, We have owner design term and advance production equipments. Main products include LED module,LED strip,LED power supply, Rigid LED strip,LED controller,LED connector, etc, which are widely used in signage lighting, advertisting light decoration, advertisting liht box and commercial lighting area.


CE & RoHS Certifications:









Factory Show:



High quality 2835 smd 0.5w led module 45lm led module with lens



High quality 2835 smd 0.5w led module 45lm led module with lens





FAQ



 Q1: Can I have samples to test?
A: Yes,we are pleased to supply samples to test and check quality,mixed sample order is available. Please note, free samples within 10pcs. and buyer pay for shipping cost.
Q2: Do you have any MOQ limited?
A: Our MOQ is 5000pcs.
Q3: What’s the lead time?
A: Sample :1-5days. Mass production: 7-10days.
Q4:How do you ship the goods and how long does it take?
A: We usually ship by DHL,UPS,FEDEX,TNT. It usually takes 3-5days to arrive.By air,by sea are also acceptable.
Q5: Do you offer guarantee for your products?
A: Yes, we offer 3-5 years guarantee for the products.
Q6: Do you accept drop shipping
A: Yes, it is available.
