marine gearbox,ship gear case,ship transmission case,marine transmission part,gearbox,marine engine and gearboxMarine gearbox model: 06 is the series products manufactured by FENJIN company. It is a kind of mechanically operated power transmission unit designed for small crafts.
Marine gearbox 06 is simple in construction, easy of assembling and disassembling, and convenient for maintenance.
Marine gearbox 06 performs the duties of ahead and astern drives, clutching and declutching, as well as as the reduction of speed.
Power/speed(kw/rpm): 4.4/1000~9.2/2100
Rated thrust propeller: 1.8KN
Center distance: 124mm
Bell housing: 195C
Flywheel: 195C
L*W*H: 350*316*482mm
Net weight: 58kg
Control type: Manual control
Partial engine: 195C285CYANMARTS130TS155...
Marine gearbox: 06
|
Description |
symbols |
Unit |
Technical parameters and specification |
Type 06 | |||
Rated transmission power |
p n |
KW/(r•min-1) |
0.044 (0.006) |
Rated speed of input shaft |
n |
r•min |
2100 |
Rated transmission torque |
T |
N•m |
42.1 (4.3) |
Rated propeller thrust |
Fr |
N |
1764 (180) |
Time required for reversing |
t |
s |
less than 10 |
Force applied to the handle of control lever while reersingunder running conditions |
Fr |
N |
98~147 (10-15) |
Direction of rotation of the output shafte (facing the output end) |
Z |
— |
Left-handed turning (counter-clockwise) |
Direction of rotation the output shaft(ahead drive) |
F |
— |
Contrary to the direction of rotation of the input shaft |
Centre distance |
a |
mm |
124 |
|
Overall dimensions (with connecting housing) |
1×b×h |
mm |
350×445×482 |
|
Net weight* (with connecting housing) |
m |
Kg |
58 |
Matched Engine: 195C, 285C, TS155YANMAR, TS130
Elastic pin drive or rubber disk drive.
Stable and reliable machinery control clutch, easy.
