Help CenterDouble-column Vertical Lathe
US$ 1 - 2
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Vertical
CNC or Not:
CNC
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Condition
New
Type
Vertical
CNC or Not
CNC
Automatic Grade
Automatic
Max. Swing Diameter
6300 mm
Place of Origin
China
Brand Name
Smartech
Model Number
DVT-630
Voltage
380 V
Power(W)
AC55 / DC75 Kw
Weight
108000 Kg
Specifications
Vertical lathe ;high rigid structure for heavy duty ;
Easy to operate
Main Features:
- 1. This series machine is suitable for finely and roughly turning cylinder and inner hole,inner and outer taper surfacing, grooving of the ferrous, nonferrous
- metal and some kind of non-metal materials with carbide alloy porcelain tools.
- 2. Feed is driven by AC servo motor, transmitted by ball screw. The universal type has such construction that can be rebuilt into CNC type.
- 3. By the exchange of machine spindle motor drive, with 16 vertical shaft speed, to achieve the speed of table.
- 4. Table for the hot symmetrical structure. Workstations using high-precision spindle adjustable redial clearance double row cylindrical roller bearings
- short centering. Use constant current axial pressure rails, table rotation with high accuracy, large capacity, small heat distortion characteristics.
5. Holders of the vertical guide rails for HIP unloading. Ram vertical movement for the sliding rails.
Main Specifications:
| Specification | Unit | Model | ||||
| CVT280×H/W | CVT350×H/W | CVT400×H/W | CVT500×H/W | CVT630×H/W | ||
| Max. turning diameter | mm | 2800 | 3500 | 4000 | 5000 | 6300 |
| Table diameter | mm | 2400 | 3150 | 3150 | 4500 | 4500 |
| Max height of work piece | mm | 1800 | 2000/2800 | 2000/2800 | 2800/3150 | 2800/3150 |
| Max weight of work piece | t | 16 | 32 | 32 | 40 | 40 |
| Horizontal travel of head | mm | 1600 | 1840 | 2250 | 2765 | 3350 |
| Cutting force of right head | KN | 35 | 35 | 35 | 40 | 40 |
| Cutting force of left head | KN | 30 | 30 | 30 | 35 | 35 |
| Swivel of left and right | ±30° | ±30° | ±30° | ±30° | ±30° | |
| Max torque of table | KN.m | 63 | 80 | 80 | 80 | 80 |
| Section dimension of ram | mm | 220X220 | 220X220 | 220X220 | 240X240 | 240X240 |
| Vertical travel of ram | mm | 1250 | 1250/1400 | 1250/1400 | 1400/1600 | 1400/1600 |
| Power of main motor | KW | AC 55 | AC 55 | AC 55 | AC55/DC75 | AC55/DC75 |
| Speed range of table | r/min | 2~64 | 1.6~50 | 1.6-50 | 1.25~40 (16 steps) | 1.25~40 (16 steps) |
| (16 steps ) | (16 steps) | (16 steps) | 0.5~50 (II steps) | 0.5~50 (II steps) | ||
| Rapid travel of head | mm/min | 4000 | 4000 | 4000 | 4000 | 4000 |
| Guideway pair of table | Hydrodynamic | Hydrostatic | Hydrostatic | Hydrostatic | Hydrostatic | |
| Torque of feed motor | N.m | 48 | 48 | 48 | 48 | 48 |
| Weight of machine(approx) | kg | 45000 | 56000 | 62000 | 98000 | 108000 |
| The company remains the right to modify the specification without notice here. | ||||||
Details Photos
