Help CenterSLANT BED TYPE CNC Lathe CK 40 & CK50
Related Products
Specifications
CNC LATHE CK40 and CK50High rigid , high precision and high quality
CNC LATHE CK40 and CK50
Fanuc controller or GSK980TDa
Optional : bar feeder
Brief specification ,for other model , please contact us !
Item |
Unit |
CK40 |
CK50 |
|
Capacity |
Max. swing over bed |
mm |
Φ400 |
Φ500 |
Max. swing over carriage |
mm |
Φ260 |
Φ320 |
|
Max. turning diameter |
mm |
Φ165 |
Φ210 |
|
Max. turning length |
mm |
400 |
530 |
|
Max. bar diameter |
mm |
Φ42 |
Φ51 |
|
Spindle |
Spindle thru hole |
mm |
Φ57 |
Φ62 |
Type of Spindle nose |
|
A2-5 |
A2-6 |
|
Spindle speed |
r/min |
70-3000 |
60-2250 |
|
Hyd. chuck dia. |
mm |
Φ165 |
Φ210 |
|
Main motor power |
Kw |
7.5 |
15 |
|
Tailstock |
Quill diameter |
mm |
Φ70 |
Φ90 |
Quill travel |
mm |
80 |
100 |
|
Taper of center |
|
MT No.4 |
MT No.5 |
|
Carriage |
X/Z-axis travel |
mm |
165 / 410 |
210 / 550 |
X/Z Rapid traverse rate |
m/min |
12 / 16 |
12 / 16 |
|
X/Z servo motor torque |
Nm |
11/20 |
11/20 |
|
X/Z ball screw dia. |
mm |
Φ20/Φ40 |
Φ20/Φ40 |
|
Turret |
Number of stations |
|
8/12 |
8/12 |
Tool size (turning / boring) |
mm |
20x20 / Φ32 |
20x20 / Φ40 |
|
Other |
Power source |
kVA |
35 |
35 |
Dimension (LXWXH) |
mm |
2540 x 1670 x 1660 |
3060 x 1810 x 1850 |
|
Gross weight |
kg |
3000 |
4500 |
|
Send Inquiry to This Supplier
