Vertical Machining Center VMC 850C

Vertical Machining Center VMC 850C thumbnail-1
Vertical Machining Center VMC 850C thumbnail-2
Vertical Machining Center VMC 850C thumbnail-3
Vertical Machining Center VMC 850C thumbnail-4
Vertical Machining Center VMC 850C photo-1
Vertical Machining Center VMC 850C photo-2
Vertical Machining Center VMC 850C photo-3
Vertical Machining Center VMC 850C photo-4
US$ 16,700 - 17,500 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Yunnan, China
Brand Name:
SMARTECH
Contact Supplier Request Quote Chat Now
Smartech Machinery & Equipment Co., Ltd.(Shenzhen)
Payment & Shipping
Payment Methods:
Port of Shipment:
SHENZHEN CHINA
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Place of Origin Yunnan, China
Brand Name SMARTECH
Model Number VMC850C
Type Vertical
CNC or Not CNC
Voltage 380 V
Power(W) 5.5-7.5 (recommended spindle motor)
Dimension(L*W*H) 2200*2300*2500mm
Weight 4500 Kg
Certification CE
Warranty one year

SMARTECH CNC VMC FRAME

  • MACHINE FEATURE:

1     High-class casting by resin sand and wood mould;

2     Top class imported ball screws sets and bearing ;

3     Imported spindle & tool clamping system ;

4     Imported drive connectors ;

5     Stainless steel telescopic protection on X/Y/Z axis ;

6     Central lubrication system ;

7     Coolant system ;

8      Harden&ground on all slideways and Turcite-B coated with precise scraping;



  • OPTIONAL:

1     Spindle from Taiwan;

2     Direct drive structure for main motor with spindle ;

3     Central oil coolant for the spindle ;

4     Coolant through spindle ;

5     ATC: drum type, arm type or chain type ;

6     Outside guarding: standard or special made according to clients design

7     Chip conveyor

8     CNC pre-installed for clients: whole full ready package delivery according to clients design



  • SPECS:

MODEL

VMC-850C

Table Size

530 x 1000

Travel X

800

Y

500

Z

700

Spindle to Column Slideway

575

Spindle Nose to Table Surface

110-810

T-Slot(No-size/distance)

5-18/100

Spindle Taper/outside dia

BT40/150

Spindle Speed

8000rpm

X,Y axis Ball Screw Spec.

40/10

Z axis Ball Screw Spec.

40/10

X,Y & Z Motor Connection

Direct drive

Main motors recommended

5.5-7.5w

Drive motors recommended X/Y/Z

10/12/12Nm

Table  Work Load

600 Kg

Net Weight

4500kg

                                          *Also provide linear-type slide ways.
