SMARTFOLD 1100 is specially indicated for the most demanding packaging companies, commercial printers and finishers. Can run from small to large sized boxes,covering a wide range of industries. It is flexible to operate and it comes with a state of the art technology and electronics.The standard version includes the accessories for straight line and crash lock bottom boxes.It is flexible and easy to operate.
2.Technical parameters
Specifications
| Processed materials | |
| Carton board | max .800gsm |
| Corrugated flute tyep | N,E & F |
| Capablity | |
| Speed | max. 400m/min |
| Inching speed | 10m/min |
| Thickness of folded box | max. 20mm |
| Blank width | 1100mm |
| Dimensions & Weight | |
| Length | 15m |
| Width | 1.7m |
| Height | 1.9m |
| Net Weight | 4.7Ton |
| Installation | |
| Electrical connected load | 15KW |
| Compressed air | 6 bar |
| Air compressor capacity | 10 m³/h |
| Air tank capacity | 60L |
BOXES
|
Straight Line A:126-1100mm B:60-800mm |
|
Lock-bottom Box A:146-1100mm B:max.700mm C:min.60mm D:20-180mm
|
|
4-corner Box
A:120-1100mm
B:130-800mm
C:20-150mm
D:80-800mm
|
|
|
6-corner Box
A:250-1100mm
B:130-800mm
C:30-150mm
D:80-325mm
|
Key Components
| Picture | Description |
|
1). Feeder section:
|
|
2).Side register section
|
|
|
3).Pre-folding section:
|
|
|
4).Crash lock bottom section
|
|
|
5)Lower gluing Unit
|
|
|
6). Folding and Closing section:
|
|
|
7).Trombone section:
|
|
|
8.Press section(Delivery section):
|
|
|
9).4 and 6-corner device
|
|
|
10).Servo-motor of back folding device
|
DGM WORLDWIDE CARTON CONVERTING EQUIPMENT
With more than 20 years in the business, designing and producing folding gluing machines, die-cutting machines, hot foil-stamping machines and carton laminator machines, DGM has became the leading supplier in Southeast Asia market and one of leading suppliers in China market. Based on this foundation, DGM machinery has its presence in over 25 countries with 5000 units sold.
GLOBAL SOLUTION
DGM Machinery provides 360 º services . Service process, DGM not only embodies in to pre-sales service, such as helping the customer get to know DGM products, enhancing customer confidence in DGM products, knowing customers’s individual needs etc.,but also in to after-sales service which is the most important aspect to make a big gap from other carton converting manufactures. DGM’s core after-sales service includes:
• Technical services
• Training
• In-depth inspection and Maintenance
• Spare parts and consumables.
• Machine improvements
Huizhou De Gang Machinery Co.,ltd
HuiHuan Industrial Area, Huizhou City, Guangdong Province, China
Tel:(86) 0752-277 37 80
Fax:(86) 0752-277 37 78
