Automatic Hot Foil Stamping &Die Cutter Machine
- 8 Set / Sets per Month
- SHENZHEN
- T/T
- Infrared and circulating air dryer Printing Ink Tunnel Oven Machine
- big size Automatic screen printing machine for sheet with automatic blanking
- Printing Ink Tunnel Oven Machine
- Ozone-free energy saving and environmental protection LED uv curing machines
- Round/Plane Surface UV Drying Machine
- Bottle UV Drying Machine
Product Details
Condition: | New | Type: | Paper Cutting Machine | Automatic Grade: | Automatic |
Place of Origin: | Guangdong, China | Brand Name: | DGM | Model Number: | Technocut1050s |
Voltage: | 380V | Power(W): | 15kw | Dimension(L*W*H): | 6.1m*4.2m*2.45m |
Weight: | 16Ton | Certification: | CE | Warranty: | 12months |
After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Depending on the selected model the Technofoil can process die-cutting and embossing jobs,with or without stripping unit. It can also work with two different stamping systems,using longitudinal or transversal foil feeding or if you choose it can even have both installed on the same machine working at the same time.
Using longitudinal axle you have the option of making holograms.
High precision,high speed,easy to operate,quick changeovers,durability and stable performance. Features that make this machine one of the best options available in the market.
Processed Materials | |
Paper | from 80g/m2 |
Carton board | max.2000g/m2 |
Corrugated board | max.4mm |
Capability | |
Sheet size | min.360*400mm |
Sheet size | max.740*1050mm |
Speed | 7500s/h |
Cutting force | 300Ton |
Converting | |
Stamping & embossing size | max.720*1020mm(Longitudinal) |
Stamping & embossing size | max.580*1020mm(Transversal) |
Die cutting size | max.730*1040mm |
Heating System | |
Heatig Zones | 12 units |
Temperature | max.200 º C |
Foil Equipment | |
foil length | 120 to 1200 mm |
Longitudinal | Web width 50 to 1020 mm Web advance shafts 4 |
Transverse | Web width 50 to 630 mm Web advance shafts 2 |
Pile Height | |
Feeder | 1600mm |
Feeder with non-stop | 1100(1500)mm |
Delivery | max.1300mm |
Dimensions &Weight | |
Dimensions | 7.07*4.2*2.45m |
Weight | from 16 to 18 Ton |
Installation | |
Compressed air | 6 bar |
Air compressor capacity | 30 m3 |
Air tank-capacity | 120 L |
B. Key components:
Components | Description |
1). Feeder section:
| |
2).Register table
| |
3).Press section
| |
4).Foil stamping system
| |
6).Transverse shaft
|
With more than 20 years in the ing and producing folding gluing machines,die-cutting machiens,hot foil-stamping machines and carton laminator machines,DGM has became the leading supplier in Southeast Asia market and one of leading suppliers in Chia market.Based on this foundation,DGM machinery has its presence in over 25 countries with 5000 units sold
Bussiness development
Workshop
DGM Machinery provides 360° services.Service process,DGM not only embodies into presales service,such as helping the customer get to know products,enhancing customer confidence in DGM products, knowing customer individual needs etc.,but also in to after sales service which is the most important aspect to make a big gap from other carton converting manufactures.DGM after sales service includes
-Techical services
-In-depth inspection and Maintenance
-Spare parts and consumables
-Machine improvements
