API Truck-mounted Drilling Rig

Name: API Truck-mounted Drilling Rig
Brand: SENWELL
SKU: 123849943

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

China

Brand Name:

SENWELL

Shaanxi Senwell Import & Export Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

China Main Port

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin China

Brand Name SENWELL

Specifications

biggest self-propelled
Truck-Mounted Drilling Rig
API oil drilling rig

Truck-mounted Rig

Detail Specification:

Technical specifications and parameters for 1000m Truck-mounted Rig.
Model	ZJ10/1125CZ
Drilling depth: m(ft)(4 1/2”DP)	1000M (3280)
Well servicing depth: m(ft)(3 1/2”DP)	3500M (11483)
Max. Hook Load: KN(lb)	1125 (253000)
Rope line Diameter: mm(in)/number	26 (1”) /8
Max. hook lifting speed: m/s(ft/s)	1.23 (4)
Moving dimension: m(ft)	17.5 × 3.1 ×4.18 (57.4 ×10.17×13.7)
Weight: kg(lb)	42000 (92590)
Power system	CAT3406C/C15
Engine power: KW(hp)(2100r/min)	343 (460)/ 335 (475)
Model of hydraulic transmission	Allison-S5600DB
Emergency power	Select
Chassis driven	10 × 8 (8 ×8)
Min. turning radius: m(ft)	34 (111.55)
Min. ground clearance: mm/in	340/13.39
Drawwork	Double drum (single drum)
Drawwork power: hp	450
Diameter of main drum: mm(in)	429 × 965 (16.9×38)
Main brake	Belt type(disc type can be chosen)
Auxiliary brake	22”SR hydro brake (WCB can be chosen)
Drawwork lifting shifts	5 forward 1 reverse
Derrick model (double sections extension mast)	JJ119/33.1-W
Derrick height: m(ft)	31.3 (102.69)
Racking platform	19.7/20.7 (55.77/64.6)
Wind speed: km/h (kn)	110 (60)
Control/ lighting/ electric circuit	24V/220V/380V (China)
Rated pressure of hydraulic/air: Mpa (psi)	14/0.833~0.93 (2002/119.12~133)
Rig floor	DZ135/3.7-S telescoping substructure
Rotary table	ZP175(ZP105)
Traveling block/hook	YG150
Swivel	SL120
