Specifications
Fully Automatic Aluminium Foil Container Making Machine:1.Pass ISO 9001:2008,ce
2.Easy Operation,good quality
3100%food safe
Fully Automatic Aluminium Foil Container Making Machine is our main product, after 8 years' producing experience and listenning to customer's suggestion,we update our machine to the 3nd generation, the whole line include below machines:
Auto-lubricated feeder -- control panel -- length controller-- 45T pneumatic press --mould-- full-automatic stacker—Scrap Presser (Optional)
In order to make sure the top quality of the machine, after our research we adopt imported Seimens motor & PLC and Schneider electronic componets, and these years,according to customer's target price we make some lines in Middle east countries, South African, East Europe, get very good response from our customers.
Precision processing technics,aluminum foil container cutting,forming ,stretching,turned edge with one step forming.
Below is our machine spec. and machine parts photos:
Main Technical datas as below:
ITEM |
CYAL-45T |
CYAL-63T |
Strokes |
40-75times/min |
30-70times/min |
Motor Capacity |
6.5KW |
8KW |
Voltage |
3-380V 50HZ 4wires |
3-380V 50HZ 4wires |
Total Weight |
6500KGS (approximate) |
7500KGS (approximate) |
Area |
7mx3m |
7.5mx3.5m |
Press Dimension |
1620x1050x2960 |
1820x1250x3080 |
Core Coil Head Dia |
3min/6inch |
3min/6inch |
Max. Foil Roll Outer Dia |
700mm |
800mm |
Max. Foil Width |
550mm |
670mm |
Machine Parts:
Auto feeding part:
Pneumatic press:
Mould:
Auto Stacker:
Finished Products:
