Hybrid Coupler /2:2 Combiner--800-2500MHz N-Female
Applications:
1. Mobile Communication Network Optimization and In-door distribution system.
2. Cluster communication, satellite communication, shortwave communication and hopping radio.
3. Radar, electronic navigation and electronic confrontation.
4. Aerospace equipment systems
Hybrid Coupler /2:2 Combiner---800-2500MHz N-Female (Model No.:HT.HCP-0825-031118) | |||||
| Electrical Specifications: | |||||
| Frequency Range(MHz) | 800-2500 | ||||
| VSWR | ≤1.2:1 | ||||
| Insertion Loss (dB) | ≤3.5 | ||||
| In-band Ripple (dB) | ≤0.5 | ||||
| Isolation (dB) | ≥25 | ||||
| 3rd Order IMD(dBc) | ≤-120 @2 x 43dBm | ||||
| Average Power(W) | ≤200 | ||||
| Impedance(Ω) | 50 | ||||
| Connectors | N-Female | ||||
| Operating Temperature(°C) | -30~ +50 | ||||
| Net Weight(g) | 300 | ||||
| Finish | Black Plated | ||||
Who we are?
1. We have 23 years' experience in designing and production of RF/Microwave components.
2. Products are widely used in GSM, DCS, CDMA, 3G/4G communication system, satellite orientation, radar and military fields.
3. Over 16 series and 1000 designs products including Power Splitter, Directional Coupler, Hybrid Coupler/Combiner, Attenuator, Dummy Load/Termination, Connector/Adapter, Cable Assembly, Diplexer and Combiner.
Why Choose Us?
1. OEM/ODM, customers' design are available.
2. Sufficient stock for your urgent demand.
3. Within 12 hours' reply guarantee.
4. Fast delivery and volume production capacity.
or/Adapter, Cable Assembly, Diplexer and Combiner.
More Hybrid Couplers/Combiners:
International and Domestic Exhibitions:
Production Lines & Warehouse:
Packing Details (Packing Boxes & Cartons):
Transportation(By Sea, By Air, DHL, Fedex, TNT & EMS):
