wireless 1km-3km outdoor video rf transmitter receiver
---SG-F3000A
Introduction
This product transmits the video signal by wireless microwave. There are three main frequency band: L-Band 1.0-2.0GHZ; S-Band 2.3-2.7GHZ; KU-Band 10.75-12.7GHZ. As selection of a higher frequency, it has a strong anti-interference performance, clearer images and real-time stability. It has been well received in wireless video projects by users.
Transmitter System Indicators | |
Frequency |
1000-1500MHz (L-Band 1.0G-1.5G ) |
RF Power |
3W |
Power Supply |
12vDC/220v |
Modulation |
FM |
Frequency stability |
0.0005%(standard) |
Impedance |
50Ω |
Phase Noise @10KHz |
-75dBc |
Bandwidth |
20MHz |
RF Interface |
N |
Work environment |
-30~70 |
Video Format |
PAL |
Size |
250*180*110mm |
Transmission distance |
1-3km |
Receiver System Indicators | |
Frequency |
1.0-1.5G (optional) |
Impedance |
75Ω |
Video Output |
Analogic AV signal |
Voltage |
AC220V |
Current |
0.6A |
Interface |
BNC |
Temperature |
-30~50°C |
Humidity |
0.96% |
Weight |
1.5KG |
Size |
250*150*110mm |
Audio index | |
Audio Output |
600ΩBalance/ 0.5vImbalance |
De-emphasis |
75us/50us |
Frequency corresponding |
50Hz to 15KHz(+/-0.5dB) |
Carrier frequency |
6.5MHz |
AV Interface |
BNC |
Distortion |
3% |
FM Noise |
-50dB |
Video Index | |
Video Output |
75 Ω unbalanced, 1.0Volt P-P |
Differential gain |
5% |
Differential phase |
5 |
SNR |
55dB |
De-emphasis |
CCIR STANDARD PAL |
Transmitter interfaces:
-----------------------------------------------------------------------------------------------------------------------------------------------------------
Receiver interfaces:
- One year free warranty;
- three months for free spare parts (Replacement parts will be charged after a year);
- 24-h technical guidance;
- One-stop ODM/OEM solution;
- We provide professional system design and construction;
- We have over 15 years experience in study, design and manufacturing in wireless microwave transmission area;
- We are the professional plant source,so we can provide you high quality in best price.
