Home > Electrical & Electronics > Passive Components > Resistor & Potentiometer > F-17N Carbon Rotary Potentiometer
US$ 1 - 2
MOQ: 1000 Pieces
Key Specifications
Get Latest Price
Brand Name:
PANKAJ
Model Number:
F-17N
Resistance:
100Ω- 1MΩ
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo or shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
F-09NP Thumbwheel Driving Carbon PotentiometerUS$ 0.3 - 5MOQ: 1000 Pieces -
2WDD35D-4 1k Linear Dual PotentiometerUS$ 80 - 200MOQ: 5 Pieces
-
SR-082C 16mm Potentiometer RotaryUS$ 0.5 - 5MOQ: 1000 Pieces
-
WX14-12 13mm Rotary PotentiometerUS$ 0.5 - 5MOQ: 1000 Pieces
-
Linear (B) Taper Trimmer PotentiometerUS$ 0.1 - 5MOQ: 10000 Pieces
Brand Name
PANKAJ
Model Number
F-17N
Resistance
100Ω- 1MΩ
Resistance Tolerance
±20%
Rated Power
Linear B: 0.1W, other linearity: 0.05W
Max. Operating Voltage
1minute at AC 500V
Operating Temperature
/
Specifications
F-17N carbon Rotary PotentiometerResistance Range 50Wto 50KW Resistance Tolerance +10 % Standard,+5 % special
F-17N carbon Rotary Potentiometer
Model: F-17N
Total Resistance: 100Ω- 1MΩ
Total Resistance Tolerance: ±20%
Impedance characteristics patterns: A, B, C, D
Max. Working Voltage: Linearity B: AC 200V, other linearity: AC 150V
Power rating: Linear B: 0.1W, other linearity: 0.05W
Noise: Less than 100mV
Dielectric Strength: 1minute at AC 500V
Residual Resistance: Term.1~2: Less than 10Ω Term.2~3: Less than 10Ω
Switch loop: S.P.S.T
Touch resistance value of the switch: Less than 50mΩ
Power rating of the switch: 1.0A at AC/DC 12V
Total rotary angle: 260±10(degree)
Rotary Torque: 15~200 gf.cm
Push-pull strength: Push: 8.0kgf Min
Rotary angle for switch: 40±5(degree)
Switch torque: 150~450 gf.cm
Rotational Life Expectancy: 1,0000 Cycles
....
