Ultrasonic Frequency Induction Forging Generator (JLC-60KW)
- 1000 Set / Sets per Month
- Shenzhe/Guangzhou/Hongkong
- T/T L/C D/P D/A Credit Card PayPal
You May Like
-
Electric Induction Forging Furnace For Steel Round Bar (JLC-80KW)
-
Jinlai Electromechanical Induction Hot Forging Plant (JLC-80KW)
-
Utensil Annealing and Tempering Inductive Heater (JLC-60KW)
-
China Manufacture Induction Hardening Quenching Equipment (JLC-60KW)
-
Shaft Hardening Induction Heat Treatment Machinery (JLC-60KW)
-
50KW IGBT Induction Shaft Quenching Machine (JLC-50KW)
Product Details
| Condition | New | Place of Origin | Guangdong, China | |
| Brand Name | Jinlai | Model Number | JLC-60KW | |
| Voltage | 3 phase 380V | Power(W) | 60KW | |
| Weight | 120KG | Certification | ISO9001:2008,SGS,CE | |
| Warranty | 1 year | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Specifications
Ultrasonic Frequency Induction Forging Generator1.IGBT technology.
2.Perfect protection function.
3. Converting frequency.
Ultrasonic Frequency Induction Forging Generator
1) Feature:
1. IGBT inversion technology reduce operating cost
2. High efficiency up to 90%
3. LC series circuit and voltage feedback design achieve energy saving up to 30% compared with SCR technology induction machine
5. Diode rectification technology make sure high power factor –never less 0.95
6. Soft switch technology and prefect protection system enhance good reliability
7. Suitable for heating medium size of part.
2) Specifications:
Model | JLC-60KW | |
Input power desire | 3 phase 380V 50/60HZ | |
Oscillate power max | 60KW | |
Max input current | 90A | |
DC current | 120A | |
Oscillate frequency | 10-30KHZ | |
Timing | 1M-99.99M 1S-99.99S 0.01S-99.99S | |
Cooling water desire | 0.3Mpa | |
Duty cycle | 100% 40°C | |
Dimensions(L*W*H) | Generator | 510*540*980mm |
transformer | 560*430*540mm | |
Net weight | 80kg/55kg | |
Cable length | 2-6(Meters) | |
3) Spare parts for JLC-60KW Machine
Item | Name of machine or parts | Specification | Amount |
1 | JLC-60KW Generator | - | 1 pc |
2 | JLC-60KW Transformer | - | 1 pc |
2 | Foot switch | 3 core | 1 pc |
3 | Induction Coils | - | 3 sets |
4 | Coil connect pole | - | 3 set |
5 | Instruction Manual | - | 1 |
6 | Packing list and receipt | - | 1 |
7 | Guarantee card | - | 1 |
8 | Products certificate | - | 1 |
4) Application:
1. Pre-heating for forging and forming
2. Brazing
3. Heat treatment such as surface hardening
4. Melting for aluminum, copper etc
5. Pipe Pre-heating and soak before after weld
6. Pipe heating for elbow machine
