Help CenterShaft Hardening Induction Heat Treatment Machinery (JLC-60KW)
Related Products
-
50KW IGBT Induction Shaft Quenching Machine (JLC-50KW)US$ 1,000 - 100,000MOQ: 1 Set -
Ultrasonic Frequency Induction Heating Forging System (JLC-50KW)US$ 1,000 - 100,000MOQ: 1 Set
-
Induction Heating Unit For Metal Forging Press (JLC-50KW)US$ 1,000 - 100,000MOQ: 1 Set
-
IGBT Inverter Used Electric Forging Machine (JLC-50KW)US$ 1,000 - 100,000MOQ: 1 Set
-
Superaudio Frequency Induction Heating Unit (JLC-30KW)US$ 1,000 - 100,000MOQ: 1 Set
Specifications
Shaft Hardening Induction Heat Treatment Machinery1.IGBT technology.
2.Perfect protection function.
3.Converting frequency.
Shaft Hardening Induction Heat Treatment Machinery
1) Feature:
1. IGBT inversion technology reduce operating cost
2. High efficiency up to 90%
3. LC series circuit and voltage feedback design achieve energy saving up to 30% compared with SCR technology induction machine
5. Diode rectification technology make sure high power factor –never less 0.95
6. Soft switch technology and prefect protection system enhance good reliability
7. Suitable for heating medium size of part.
2) Specifications:
Model | JLC-60KW | |
Input power desire | 3 phase 380V 50/60HZ | |
Oscillate power max | 60KW | |
Max input current | 90A | |
DC current | 120A | |
Oscillate frequency | 10-30KHZ | |
Timing | 1M-99.99M 1S-99.99S 0.01S-99.99S | |
Cooling water desire | 0.3Mpa | |
Duty cycle | 100% 40°C | |
Dimensions(L*W*H) | Generator | 510*540*980mm |
transformer | 560*430*540mm | |
Net weight | 80kg/55kg | |
Cable length | 2-6(Meters) | |
3) Spare parts for JLC-60KW Machine
Item | Name of machine or parts | Specification | Amount |
1 | JLC-60KW Generator | - | 1 pc |
2 | JLC-60KW Transformer | - | 1 pc |
2 | Foot switch | 3 core | 1 pc |
3 | Induction Coils | - | 3 sets |
4 | Coil connect pole | - | 3 set |
5 | Instruction Manual | - | 1 |
6 | Packing list and receipt | - | 1 |
7 | Guarantee card | - | 1 |
8 | Products certificate | - | 1 |
4) Application:
1. Pre-heating for forging and forming
2. Brazing
3. Heat treatment such as surface hardening
4. Melting for aluminum, copper etc
5. Pipe Pre-heating and soak before after weld
6. Pipe heating for elbow machine
