Copolymer Coated Aluminum Foil Tape for Cable

FOB Price

US$ 2,800 - 3,700 / Ton

1 Ton(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Zhejiang, China	Brand Name	Tianhong
Model Number	AL+PE	Type	Other, Customer requirements
Material	Other, AL+PE	Application	High Temperature
Rated Voltage	min 2kv	Tensile Strength	min 50mpa

1.Tensil strength: min 50 MPA
2.Product pass certificate:ISO9001:2008

Copolymer coated aluminum foil tape used for cable
Product pass certificate:ISO9001:2008

1)Tensil strength: min 50MPA

2)Elogation: min 15%

3)Foil thickness: 0.15,0.02 +-0.015mm

4)Coating thickness: 0.05+-0.012mm

Application:

1.For optical cable,telephone cables, telecommunication cable

2.Used as waterproof materials

3.For cable shielding

4.Widely used in electronics, electrical, telecommunication

Specifications:

Thickness, length and width can according to customer requorements.

Name	Single side Co-Polymer coated Aluminum Tape
Thickness	150µ-600µ
Width	17mm-600mm
ID(inner diameter)	53.5mm / 76mm / 102mm / 150mm (2.1in / 3.0in / 4.0in / 5.9in)
ID material	Plastic or Metal
OD(outer diameter)	500-900mm
Length	1000m-2050m
Color	Silver/Green/Blue
Packaging	1.Carton,Then put on a plywood pallet 2. Inner-plastic bag,Outside-carton,Then put on a plywood pallet

Name	Double side Co-Polymer coated Aluminum Tape
Thickness	200µ-600µ
Width	17mm-600mm
ID(inner diameter)	53.5mm / 76mm / 102mm / 150mm (2.1in / 3.0in / 4.0in / 5.9in)
ID material	Plastic or Metal
OD(outer diameter)	500-900mm
Length	1000m-2050m
Color	Silver/Green/Blue
Packaging	1.Carton,Then put on a plywood pallet 2. Inner-plastic bag,Outside-carton,Then put on a plywood pallet
