ATM machine parts chip IC/MAGNETIC/RFID card reader writer vending machine with card reader with emv certification
- 100000 Piece / Pieces per Month
- SHENZHEN
- Full-insert type motorized usb emv smart IC/MAGNETIC/RFID card reader support ISO7811/7812/7816 magnetic/IC card reader writer
- Wireless magnetic IC/MAGNETIC/RFID card reader 2016 hot selling wireless magnetic card reader
- Warp card mechanism design card reader atm skimmer mold atm bezel smart motor card reader
- 2016 hot selling ATM CRS acr122u nfc smart motor card reader
- Jitter card controlling atm machine card reader mini plastic bezel smart chip card reader
- Europe RS-232/USB Interface Automatic Card Dispenser for Parking System
Product Details
Brand Name: | CRT | Model Number: | CRT-310 |
Product Description
ATM machine parts chip card reader writer vending machine with card reader with emv certification
Quick Detail:
CRT-310 series are motorized card reader equipments for RFID/IC /magnetic stripe card operation, with the function of the card entry from front/rear insertion/ejection.
Description:
Motorized card reader CRT-310 with below main features:
² Insert and eject the card from both front and rear side
² RS232 interface
² DC12V ±5%
² Power-fail protection
² Deal with abnormal cards function
² Electric shutter and mechanical shutter for option
² PSAM board for option
² Support IAP Download
Applications:
Kiosk terminals
Payment systems
Access control terminals
Specifications:
Card standard | Magnetic Card: ISO7810 ID-1,ISO7811 IC Card: ISO7816-2 RF Card: ISO14443 TYPE A&B |
Life time | Magnetic head:500,000 passes IC card contact:300,000 passes Motor:300,000 passes |
Communication | RS232 interface |
Power supply | DC12V±5% |
Current consumption | Static Current: 110mA Peak Current: <1.5A |
Temperature/Humidity | Operation:0~50℃/0 ~ 90% RH(Non condensing) Storage:-20~70℃/0 ~ 90% RH(Non condensing) |
Dimension (LxWxH) | 148x86x48mm |
Weight | Approx 410g |
Competitive Advantage:
RFID/IC card read/write, magnetic stripe card read only.
Automatic insertion/ejection of the cards
Insert and eject card from both front and rear
Electric and mechanical shutter for option
Power-fail protection
PSAM board and LED for option
Abnormal card processing
Support IAP download
