CNC Mini Drill Press/Milling Machine - PicoMill CNC GP
Feature:
1.Standard electronic hand-wheel
2.Rigid cast-iron frame with wide dovetail guides
3.Preloaded ball screws on all axes
4.Manual central lubrication
5.Step-less spindle
Specification:
| Model | PicoMill CNC GP |
| Table set up area | 450X160 mm |
| Throat | 232mm |
| Drilling capacity | 25mm |
| Slot milling up to | 20mm |
| Spindle nose-to-table surface distance | 250mm |
| Travel X/Y/Z axis | 254/105/80m |
| Spindle speed | 150-2000rpm |
| Spindle mount | MK3/MT3 |
| Cutter head diameter (max.) | 80mm |
| Positioning accuracy X/Y/Z axis | 0,01 mm |
| Repeatability X/Y/Z axis | 0,01 mm |
| Motor rating main drive | 1KW |
| Supply voltage | 230V |
| Overall dimensions (length x width x height) | 830x800x1700 mm |
| Weight | 391kg |
Standard Equipment:
GPlus 450 control, drill chuck Ø 1 - 13 mm, central lubrication, base, operating tools, operating manual and programming instructions
The Tengzhou Datong Machine Tool Co.,Ltd. is one of the leading manufacturers and exporters of machine tools in Shandong Province in China. We are specialized in the manufacturing of the XW series Universal Lifting Platform Milling Machine,the XQ series Universal Swivel Head Milling Machine,the ZX series Universal Drilling and Milling Machine,the ZQ serie Universal Radial Drilling Machine.Varies models of Hydraulic Machine,Automatic Boring Drum Machine,HD2006-A laser beam level truck locator and hydraulic auto-maintain equipment.
Datong has the right to import and export,and gained CE and ISO9001 System Certification.It has all the integration of R&D,manufacturing & processing,management & marketing,technical service,import & export and into one.At present,we have more than 300 employees,among them,160 have college education which more than 50 persons hold junior,middle and senior professional post .More than 200 sets of main production equipment and testing equipment.The products are widely exported to Europe,South-America and Southeast Asia and other countries and regions.
"Honesty Basic,Quality First"is the company's purpose,"continuous progress to satisfy the requirements of the customers" is the quality policy.
The Tengzhou Datong Machine Tool Co.,Ltd.sincerely wishes to cooperate with friends at home and abroad to realize mutual development!
