CNC Vertical Machining Center - X.mill 640 Eco SI for sale
Feature:
1.Reliable, compact machining center with extensive equipment for streamlined, cost-effective series productions
2.Premium linear guides and powerful servo drives on all axes
3.Solid cast-iron machine body serves as foundation for high precision at high travel speeds, and powerful chip removal
4.Totally enclosed work space with side doors ensures maximum safety and flexibility
5.Siemens 808 D control: cost-effective, easy to handle, superior reliability backed by worldwide service, including software for external programming
6.Standard electronic hand-wheel
7.Automatic central lubrication system
Specification:
| Model | X.mill 640 Eco SI |
| Table set up area | 750X360 mm |
| Table load capacity | 300kg |
| Number of T-slots/Wideth/Spacing | 3/18/100mm |
| Spindle nose-to-table surface distance | 50-550mm |
| Throat | 430mm |
| Travel X/Y/Z axis | 640/400/500m |
| Spindle speed | 8000rpm |
| Spindle mount | BT 40 |
| Rapid feed X/Y/Z axis | 30000mm/min |
| Work Feed X/Y/Z axis | 100-5000mm/min |
| Number of tool stations | 12 Pieces |
| Tool size Ø | 55 (101) mm / 2" ( 4") |
| Tool length (max.) | 200mm |
| Tool weight max. | 5kg |
| Tool-changing time chip/chip | 9S |
| Tool-change time tool/tool | 7S |
| Positioning accuracy X/Y/Z axis | 0,003 mm / 0.0001" |
| Repeatability X/Y/Z axis | 0,002 mm / 0.00008" |
| Motor rating main drive | 11KW |
| Main drive, continuous load | 7.5kw |
| Motor rating for X/Y/Zaxis drive | 4.4/4.4/5.5KW |
| Total power consumption | 45 kVA |
| Overall dimensions (length x width x height) | 1920x2200x2200 mm |
| Weight | 4200kg |
Standard Equipment:
Siemens 808D control, Electronic hand-wheel, Spiral chip conveyor, Servo drive for all 3 axes,
12-station tool changer, Pneumatic tool clamping, Control cabinet with heat-exchanger,
Totally enclosed work space, Work lamp, Tilted chip tray, Automatic central lubrication, Operating tools, Operator manual
The Tengzhou Datong Machine Tool Co.,Ltd. is one of the leading manufacturers and exporters of machine tools in Shandong Province in China. We are specialized in the manufacturing of the XW series Universal Lifting Platform Milling Machine,the XQ series Universal Swivel Head Milling Machine,the ZX series Universal Drilling and Milling Machine,the ZQ serie Universal Radial Drilling Machine.Varies models of Hydraulic Machine,Automatic Boring Drum Machine,HD2006-A laser beam level truck locator and hydraulic auto-maintain equipment.
Datong has the right to import and export,and gained CE and ISO9001 System Certification.It has all the integration of R&D,manufacturing & processing,management & marketing,technical service,import & export and into one.At present,we have more than 300 employees,among them,160 have college education which more than 50 persons hold junior,middle and senior professional post .More than 200 sets of main production equipment and testing equipment.The products are widely exported to Europe,South-America and Southeast Asia and other countries and regions.
"Honesty Basic,Quality First"is the company's purpose,"continuous progress to satisfy the requirements of the customers" is the quality policy.
The Tengzhou Datong Machine Tool Co.,Ltd.sincerely wishes to cooperate with friends at home and abroad to realize mutual development!
