Numturn 420 SI ECO CNC Cycle Lathe

Powerful CNC Technology for high flexibility and easy handling, available in 4 versions

• manually transverse the X and Z axes via 2 electronic hand wheels
• User-oriented cycle interface for easy parts programming - turning cycles with many programming options to create a complete parts program
• USB port for easy data transfers (Sinumerik 808 D on PC included in standard equipment)
• induction-hardened, ground guideways
• Longitudinal and transverse movements via high-quality preloaded ball screws and servo drives
• smart central lubrication system for low-maintenance operation

• Working area Workpiece length (max.) Turning diameter over bed Turning diameter over support Turning length (max.)	1.000 mm 420 mm 230 mm 920 mm
  Travels Travel X-axis Travel Z-axis	220 mm 920 mm
  Headstock Spindle speed Spindle mount Spindle bore Bar capacity (incl. chuck)	60 - 3.000 rpm A2-6 66 mm 60 mm
  Rapid feed Rapid feed X-axis Rapid feed Z-axis	4.000 mm/min 8.000 mm/min
  Tool head Number of tool stations	1 Pieces
  Tailstock Tailstock taper Tailstock quill diameter Tailstock quill stroke	MT 4 60 mm 100 mm
  Accuracies Positioning accuracy X-axis Positioning accuracy Z-axis Repeatability X-axis Repeatability Z-axis	0,006 mm 0,008 mm 0,005 mm 0,008 mm
  Drive capacity Motor rating main drive Motor rating coolant pump Motor rating X-axis Motor rating Z	7,5 kW 0,125 kW 1,5 kW 1,5 kW
  Measures and weights Overall dimensions (length x width x height) Weight	2.850x1.580x1.750 mm 2.750 kg

Control:
