Air Hammer C41-250Kg
Specification:
(Pneumatic Forging Hammer)(Air Power Hammer)
Pneumatic forging hammer is widely used for general forging works, such as drawing-out, upsetting, punching, chiseling, forging, welding, bending and twisting. It is also used for forge in bolster dies. Air hammer is also called forging hammer, blacksmithing hammer, pneumatic forging hammer, power hammer and so on. Air hammer falling weight at 6kg, 16kg, 20kg, 25kg, 40kg, 55kg, 75kg, 150kg, 250kg mainly for artistic wrought iron, artistic forging, blacksmith, agriculture tools and small open die forging parts.
TECHNICALSPECIFICATIONS | |||||
No. |
Name. |
Unit |
C41-250 |
||
1 |
Weight of falling parts |
Kg |
250 |
||
2 |
Max. hit energy |
Kj |
5.6 |
||
3 |
Hit number |
min -1 |
150 |
||
4 |
Distance from bottom die surface to bottom surface of lead |
mm |
450 |
||
5 |
Tup axis to hammer body |
mm |
430 |
||
6 |
Dimension of top and bottom die surface |
mm |
220x100 |
||
|
7 |
Maximum forge |
Round piece |
mm |
175 |
|
Square piece |
mm |
145x145 |
|||
8 |
Distance from bottom die surface to base |
mm |
750 |
||
|
9
|
Motor |
Type |
|
180L-4 |
|
Rate power |
kw |
22 |
|||
speed |
r.p.m |
1470 |
|||
10 |
Overall dimension |
mm |
2875x1405x2570 |
||
11 |
Anvil weight |
Kg |
2950 |
||
12 |
Total weight |
Kg |
8200 |
||
The Tengzhou Datong Machine Tool Co.,Ltd. is one of the leading manufacturers and exporters of machine tools in Shandong Province in China. We are specialized in the manufacturing of the XW series Universal Lifting Platform Milling Machine,the XQ series Universal Swivel Head Milling Machine,the ZX series Universal Drilling and Milling Machine,the ZQ serie Universal Radial Drilling Machine.Varies models of Hydraulic Machine,Automatic Boring Drum Machine,HD2006-A laser beam level truck locator and hydraulic auto-maintain equipment.
Datong has the right to import and export,and gained CE and ISO9001 System Certification.It has all the integration of R&D,manufacturing & processing,management & marketing,technical service,import & export and into one.At present,we have more than 300 employees,among them,160 have college education which more than 50 persons hold junior,middle and senior professional post .More than 200 sets of main production equipment and testing equipment.The products are widely exported to Europe,South-America and Southeast Asia and other countries and regions.
"Honesty Basic,Quality First"is the company's purpose,"continuous progress to satisfy the requirements of the customers" is the quality policy.
The Tengzhou Datong Machine Tool Co.,Ltd.sincerely wishes to cooperate with friends at home and abroad to realize mutual development!
