JC21 series pneumatic friction stamping press machine is widely used in the metal forming
industries, such as electric components, instrument and apparatus, tool and hardware, toy,
automotive, machinery, agriculture equpment. This stamping press machine is suitable for
blanking, forming, curving, flat stretching, notching, punch and staming, etc.
Features:
1. Body strength and stiffness, economy and durability.
2. Simple structure, common good, easy maintenance and operation.
Specification:
Model |
JC21-125 |
JC21-160 |
Nominal capacity (KN) |
1250 |
1600 |
Nominal pressure stroke (mm) |
6 |
6 |
Stroke of slide (mm) |
120 |
140 |
Strokes per minute |
38 |
40 |
Max. die height (mm) |
320 |
350 |
Die height adjustment (mm) |
100 |
110 |
Distance between slide center and frame (mm) |
350 |
380 |
Thickness of bolster (mm) |
110 |
130 |
Distance between columns (mm) |
520 |
640 |
Bench size (mm) |
650 × 1000 |
710 × 1120 |
Hole dimensions in bed (mm) |
Ø200 |
Ø220 |
Bottom size of slide (mm) |
420×520 |
440 ×560 |
Size of the handle hole (mm) |
Ø60×80 |
Ø65 ×90 |
Main motor power (kw) |
11 |
15 |
Overall dimension (mm) |
1900×1650×2850 |
2040 ×1765 ×3200 |
Total weight (kg) |
9500 |
12500 |
The Tengzhou Datong Machine Tool Co.,Ltd. is one of the leading manufacturers and exporters of machine tools in Shandong Province in China. We are specialized in the manufacturing of the XW series Universal Lifting Platform Milling Machine,the XQ series Universal Swivel Head Milling Machine,the ZX series Universal Drilling and Milling Machine,the ZQ serie Universal Radial Drilling Machine.Varies models of Hydraulic Machine,Automatic Boring Drum Machine,HD2006-A laser beam level truck locator and hydraulic auto-maintain equipment.
Datong has the right to import and export,and gained CE and ISO9001 System Certification.It has all the integration of R&D,manufacturing & processing,management & marketing,technical service,import & export and into one.At present,we have more than 300 employees,among them,160 have college education which more than 50 persons hold junior,middle and senior professional post .More than 200 sets of main production equipment and testing equipment.The products are widely exported to Europe,South-America and Southeast Asia and other countries and regions.
"Honesty Basic,Quality First"is the company's purpose,"continuous progress to satisfy the requirements of the customers" is the quality policy.
The Tengzhou Datong Machine Tool Co.,Ltd.sincerely wishes to cooperate with friends at home and abroad to realize mutual development!
